Kramer EXT3-C-XR-TR User Manual page 79

PRG-BTN-
Set program button
ACTION mode
PROG-BTN-
Get programmable
MOD?
buttons mode
PRIORITY Set input priority.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#PROG-BTN-
MODbtnNum,mode,actionOn,actionOff,btnBehavior<CR>
FEEDBACK
~nn@PROG-BTN-
MODbtnNum,mode,actionOn,actionOff,btnBehavior<CR><LF
>
COMMAND
#PROG-BTN-MOD?<CR>
FEEDBACK
~nn@PROG-BTN-MODbutton_mode<CR><LF>
COMMAND
#PRIORITYlayer_type,priority_1,priority_2,priority_3
<CR>
FEEDBACK
~nn@PRIORITYlayer_type,priority_1,priority_2,priorit
y_3<CR><LF>
Kramer Electronics Ltd.
btnNum – Button number 0 to 4
1 and 2 are enabled when remote
button is (mode) On
1 – IO 1 button
2 – IO 2 button
3 – Display On button
mode – Remote button state
0 – Off
1 – On
actionOn –
100 – None
101 – Switch Input
102 – Display On (via CEC)
103 – Display Off (via CEC)
104 – Mute
105 – Unmute
106 – Volume ++
107 – Volume - -
0 – Command_01
1 – Command_02
2 – Command_03
3 – Command_04
4 – Custom 5
actionOff – Button_mode
100 – None
101 – Switch Input
102 – Display On (via CEC)
103 – Display Off (via CEC)
104 – Mute
105 – Unmute
106 – Volume ++
107 – Volume - -
0 – Command_01
1 – Command_02
2 – Command_03
3 – Command_04
4 – Custom 5
– Button_mode
btnBehavior
0 – Momentary mode disabled
1 – Momentary mode enabled
– Button number 0 to 4
btnNum
1 and 2 are enabled when remote
button is (mode) On
1 – IO 1 button
2 – IO 2 button
3 – Display On button
– Remote button state
mode
0 – Off
1 – On
–
actionOn
100 – None
101 – Switch Input
102 – Display On (via CEC)
103 – Display Off (via CEC)
104 – Mute
105 – Unmute
106 – Volume ++
107 – Volume - -
0 – Command_01
1 – Command_02
2 – Command_03
3 – Command_04
4 – Custom 5
– Button_mode
actionOff
100 – None
101 – Switch Input
102 – Display On (via CEC)
103 – Display Off (via CEC)
104 – Mute
105 – Unmute
106 – Volume ++
107 – Volume - -
0 – Command_01
1 – Command_02
2 – Command_03
3 – Command_04
4 – Custom 5
– Button_mode
btnBehavior
0 – Momentary mode disabled
1 – Momentary mode enabled
– Layer Enumeration
layer_type
1 – Video
– Priority of inputs (1-2)
priority
1 – USB-C 1
2 – HDMI 2
3 – HDMI 3
Set the DISPLAY ON button
to mute/unmute with the
press of a button:
#PROG-BTN-
MOD3,1,104,105,0<CR>
Get the mode of button 3:
#PROG-BTN-MOD?3<CR>
Set the priority to first HDMI
2, USB-C 1 second and
HDMI 3 third:
#PRIORITY1,2,1,3<CR>
77
