ETH-TUNNEL?
Get an open tunnel
parameters.
FACTORY
Reset device to factory
default configuration.
This command
deletes all user data
from the device. The
deletion can take
some time.
Your device may
require powering off
and powering on for
the changes to take
effect.
FW-TYPE? Get the current FW
type status.
Used by Kramer
Network and KUpload
to identify recovery
process.
GPIO-CFG
Set HW GPIO
configuration.
GPIO-CFG? Get HW GPIO
configuration.
GPIO-STATE Set HW GPIO state.
GPIO-STATE? can
only be set in digital
out mode and the
answer is 0=Low,
1=High. In all other
modes an error
message is sent.
The device uses this
command to notify the
user of any change
regarding the step and
voltage in:
In digital mode the
answer is 0 (low), 1
(high).
In analog mode the
answer is 0 to 100.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#ETH-TUNNEL?tunnel_id<CR>
FEEDBACK
~nn@ETH-TUNNELtunnel_id,cmd_name,port_type,port_id,e
th_ip,remote_port_id,eth_rep_en,connection_type<CR><L
F>
COMMAND
#FACTORY<CR>
FEEDBACK
~nn@FACTORYok<CR><LF>
COMMAND
#FW-TYPE?<CR>
FEEDBACK
~nn@FEATURE-LISTfw_type<CR><LF>
COMMAND
#GPIO-CFGgpio_id,gpio_type,gpio_dir,pullup<CR>
FEEDBACK
~nn@GPIO-CFGgpio_id,gpio_type,gpio_dir<CR><LF>
COMMAND
#GPIO-CFG?gpio_id<CR>
FEEDBACK
~nn@GPIO-CFGgpio_id,gpio_type,gpio_dir<CR><LF>
COMMAND
#GPIO-STATEgpio_id,gpio_mode<CR>
FEEDBACK
~nn@GPIO-STATEgpio_id,gpio_mode<CR><LF>
Kramer Electronics Ltd.
tunnel_id – Tunnel ID number, * (get
all open tunnels)
– UART number
cmd_name
– TCP/UDP
port_type
0 – TCP
1 – UDP
port_id – TCP/UDP port number
eth_ip – Client IP address
– Remote port
remote_port_id
number
– Ethernet Reply
eth_rep_en
0 – COM port does not send replies
to new clients
1 – COM port sends replies to new
clients
– Connection type
connection_type
0 – not wired connection
1 – wired connection
–
Fw_type
0 – Application
1 – Safe mode (kboot)
– Hardware GPIO number (1-
gpio_id
2)
gpio_type – Hardware GPIO type
0 – analog
1 – digital
– Hardware GPIO direction
gpio_dir
0 – input
1 – output
– Enable/Disable pull-up
pullup
0 – disable
1 – enable
– Hardware GPIO number (1-
gpio_id
2)
– Hardware GPIO type
gpio_type
0 – analog
1 – digital
gpio_dir – Hardware GPIO direction
0 – input
1 – output
– Enable/Disable pull-up
pullup
0 – disable
1 – enable
– Hardware GPIO number (1-
gpio_id
2)
– Hardware GPIO state
gpio_mode
0 – Low
1 – High
Set baud rate to 9600, 8
data bits, parity to none and
stop bit to 1:
#ETH-TUNNEL?*<CR>
Reset the device to factory
default configuration:
#FACTORY<CR>
Get the current FW type
status:
#FW-TYPE?<CR>
Set HW GPIO 1
configuration:
#GPIO-CFG1,1,1,1<CR>
Get HW GPIO configuration:
#GPIO-CFG?1<CR>
Set GPIO 2 to High:
#GPIO-STATE2,1<CR>
