HDCP-OUT
Set HDCP mode.
Get HDCP working
mode on the device
input:
HDCP supported –
HDCP ON [default].
HDCP not supported -
HDCP OFF.
HDCP support
changes following
detected sink -
MIRROR OUTPUT.
HDCP-OUT?
Get HDCP mode.
Get HDCP working
mode on the device
input:
HDCP supported –
HDCP ON [default].
HDCP not supported -
HDCP OFF.
HDCP support
changes following
detected sink -
MIRROR OUTPUT.
HDCP-STAT? Get HDCP signal
status of a connected
device.
io_mode =1 – get
the HDCP signal
status of the sink
device connected to
the specified output.
io_mode =0 – get the
HDCP signal status of
the source device
connected to the
specified input.
HELP
Get command list or
help for specific
command.
IDV
Set visual indication
from device.
Using this
command, some
devices can light a
sequence of buttons or
LEDs to allow
identification of a
specific device from
similar devices.
IR-SND
Send IR command to
port.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#HDCP-OUTout_index,mode<CR>
FEEDBACK
~nn@HDCP-OUTout_index,mode<CR><LF>
COMMAND
#HDCP-OUT?out_index<CR>
FEEDBACK
~nn@HDCP-OUTout_index,mode<CR><LF>
COMMAND
#HDCP-STAT?io_mode,in_index<CR>
FEEDBACK
~nn@HDCP-STATio_mode,in_index,status<CR><LF>
COMMAND
#HELP<CR>
#HELPcmd_name<CR>
FEEDBACK
1. Multi-line:
~nn@Devicecmd_name,cmd_name...<CR><LF>
To get help for command use: HELP (COMMAND_NAME)<CR><LF>
~nn@HELPcmd_name:<CR><LF>
description<CR><LF>
USAGE:usage<CR><LF>
COMMAND
#IDV<CR>
FEEDBACK
~nn@IDVok<CR><LF>
COMMAND
#IR-SNDir_index,sn_id,cmd_name,repeat_amount,total_p
ackages,package_id,<pronto command...><CR>
FEEDBACK
~nn@IR-SNDir_index,sn_id,cmd_name,ir_status<CR><LF>
Kramer Electronics Ltd.
out_index – Number that indicates
the specific input:
1 – HDBaset OUT
– HDCP mode:
mode
0 – Follow Input
1 – HDCP always ON (i.e. output
signal is always HDCP-encrypted,
regardless of input HDCP)
– Number that indicates
out_index
the specific input:
1 – HDBaset OUT
– HDCP mode:
mode
0 – Follow Input
1 – HDCP always ON (i.e. output
signal is always HDCP-encrypted,
regardless of input HDCP)
– Input/Output
io_mode
0 – Input
1 – Output
io_index – Number that indicates the
specific number of inputs or outputs
(based on io_mode):
1 – HDBaseT OUT or USB-C IN
2 – HDMI IN
– Signal encryption status -
status
valid values On/Off:
0 – HDCP Off
1 – HDCP On
– Name of a specific
cmd_name
command
– Number that indicates the
ir_index
specific ir port:
1-N (N= the total number of inputs)
* - broadcasts to all ports
– Serial number of command for
sn_id
flow control and response commands
from device
cmd_name – Command name (length
limit 15 chars)
– Of times the IR
repeat_amount
command is transmitted
(limited to 50; repeats > 50 are
truncated to 50), default = 1
– Number of
total_packages
messages the original command was
divided into, default = 1
– Chunk serial number
package_id
(only valid when Total_packages >1)
– Pronto format
pronto_command
command (in HEX format, no leading
zeros, no '0x' prefix)
– IR Status
ir_status
0 – Sent (no error)
1 – Stop
2 – Done
3 – Busy
4 – Wrong Parameter
5 – Nothing to Stop
6 – Start
7 – Timeout
8 – Error
Set the output HDCP mode
of HDBaseT OUT to follow
input:
#HDCP-OUT1,0<CR>
Get the output
HDCP-MODE of HDBaseT
OUT :
#HDCP-OUT?1<CR>
Get the HDCP status of the
source device connected to
USB-C IN:
#HDCP-STAT?0,1<CR>
Get the command list:
#HELP<CR>
To get help for
AV-SW-TIMEOUT:
HELPav-sw-timeout<C
R>
#IDV<CR>
Send IR command to port:
#IR-SND1,1,1,1,1,1,1
<CR>
