Upgrading Firmware
To upgrade the device firmware:
1. Go to the Device > General page
2. Under General, click Update, open the relevant firmware file, and follow the instructions.
The upgrade takes approximately 30-60 seconds.
• During FW upgrade, the device continues to operate, but the device UI and protocol 3000
communication are inactive. When device restarts, the status LED is lit, and HDMI output signal is
disconnected until restart completes.
Firmware is updated.
Resetting and Restarting Device
Two types of resets can be performed:
•
Restart – Reboots your device and keeps all your device settings, including the IP
address and password.
•
Reset – Reboots your device and restores all factory settings including input/output
definitions, switching configuration, IP address and password (a DHCP-acquired IP
address is retained).
To restart the device:
▪
Click DEVICE RESTART on the Device > General page
To perform a factory reset on the device, use one of the following actions:
▪
Click FACTORY RESET on the Device > General page
▪
Using protocol 3000 commands, send FACTORY command then RESET commands.
▪
On the rear panel, press and hold the RESET button while connecting the power for
several seconds.
Exporting and Importing a Configuration File
EXT3-21-XR-TR
configuration file, that records all current device settings except the routing operation setup.
The stored file can then be imported to the same or different
the recorded settings, for configuration backup and/or solution-replication purposes.
EXT3-21-XR-TR – Using Embedded Web Pages
Figure 26:Firmware Upgrade Process
enables you to export and store (in connected browsing PC storage) a
(Figure 23).
EXT3-21-XR-TR
Kramer Electronics Ltd.
(Figure 23).
(Figure 23).
device to load
