To select Local Active Host:
1. Go to the Routing Operation page.
2. Click the Input/Output cross-point HDMI 1USB Host shown in (see
Using the local active host, you now control USB devices connected to all local devices.
Figure 14: Selecting Local Active Host for Connection to Local USB Devices Only
3. To select connection to local active host for both local and remote USB devices:
▪
Click the Input/Output cross-point HDBT 2 USB Host in addition to selected HDMI
1USB Host (see
Using the local active host, you now control all USB connected devices connected to all local and
remote devices.
Figure 15: Selecting Local Active Host for Connection to both Local and Remote USB Devices
Depending on USB active host configuration, you control local and remote USB devices via
active local host.
EXT3-21-XR-TR – Using Embedded Web Pages
Figure 15).
Kramer Electronics Ltd.
Figure 14).
