Connecting EXT3-21-XR-TR

Always switch off the power to each device before connecting it to your EXT3-21-XR-TR.
After connecting your EXT3-21-XR-TR, connect its power and then switch on the power to
each device.
To connect EXT3-C-XR-T to
1. Connect the HDBT OUT port on the
on the EXT3-21-XR-TR
13
2. On the EXT3-C-XR-T transmitter:
•
Connect a USB-C source (for example, a laptop that supports Display Port Alternate
Mode) to the USB-C IN connector.
•
Connect an HDMI LOOP connector to an HDMI acceptor.
3. On the EXT3-21-XR-TR
▪
Connect the HDMI OUT connector
projector).
▪
Connect the HDMI IN connector
(for example, a room PC).
4. Connect the USB DEVICE ports:
▪
On the transmitter side, ports to USB devices (for example, the room microphone,
mouse, and keyboard).
▪
On the receiver side, ports
soundbar and PTZ camera).
USB devices can be connected to both the transmitter and receiver sides, as
necessary.
EXT3-21-XR-TR – Connecting EXT3-21-XR-TR
Figure 3: Connecting to the EXT3-21-XR-TR Rear Panels
EXT3-21-XR-TR
EXT3-21-XR-TR
receiver side.
receiver side:
15 , to USB devices (for example, a smart board,
as illustrated in the example in
transmitter to the HDBT PoE port
to an HDMI acceptor (for example, a
14
and HOST USB-B 3.1 port
3
Kramer Electronics Ltd.
Figure 3:
