Kramer EXT3-C-XR-TR User Manual page 81

TIME-LOC
Set local time offset
from UTC/GMT.
If the time server is
configured, device
time calculates by
adding UTC_off to
UTC time (that it got
from the time server) +
1 hour if daylight
savings time is in
effect.
TIME command sets
the device time without
considering these
settings.
TIME-LOC? Get local time offset
from UTC/GMT.
If the time server is
configured, device
time calculates by
adding UTC_off to
UTC time (that it got
from the time server) +
1 hour if daylight
savings time is in
effect.
TIME command sets
the device time without
considering these
settings.
TIME-SRV Set time server.
This command is
needed for setting
UDP timeout for the
current client list.
TIME-SRV? Get time server.
This command is
needed for setting
UDP timeout for the
current client list.
TXRX-MODE
Set tx/rx mode.
This command will
reset the device and
restore factory
defaults.
TXRX-MODE? Get tx/rx mode.
UART Set com port
configuration.
In the FC-2x the
serial port is selectable
to RS-232 or RS-485
(usually serial port 1).
If Serial is configured
when RS-485 is
selected, the RS-485
UART port
automatically changes.
The command is
backward compatible,
meaning that if the
extra parameters do
not exist, FW goes to.
RS-232.
Stop_bits 1.5 is only
relevant for 5
data_bits.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#TIME-LOCutc_off,dst_state<CR>
FEEDBACK
~nn@TIME-LOCutc_off,dst_state<CR><LF>
COMMAND
#TIME-LOC?<CR>
FEEDBACK
~nn@TIME-LOCutc_off,dst_state<CR><LF>
COMMAND
#TIME-SRVmode,time_server_ip,sync_hour<CR>
FEEDBACK
~nn@TIME-SRVmode,time_server_ip,sync_hour,server_sta
tus<CR><LF>
COMMAND
#TIME-SRV?<CR>
FEEDBACK
~nn@TIME-SRVmode,time_server_ip,sync_hour,server_sta
tus<CR><LF>
COMMAND

#TXRX-MODE hdbt_port_id,hdbt_mode<CR>
FEEDBACK
~nn@TXRX-MODEhdbt_port_id,hdbt_mode<CR><LF>
COMMAND

#TXRX-MODE? hdbt_port_id<CR>
FEEDBACK
~nn@TXRX-MODEhdbt_port_id,hdbt_mode<CR><LF>
COMMAND
#UARTcom_id,baud_rate,data_bits,parity,stop_bits_mod
e,serial_type,485_term<CR>
FEEDBACK
~nn@UARTcom_id,baud_rate,data_bits,parity,stop_bits_
mode,serial_type,485_term<CR><LF>
Kramer Electronics Ltd.
utc_off – Offset of device time from
UTC/GMT (without daylight time
correction)
– Daylight saving time
dst_state
state
0 – no daylight saving time
1 – daylight saving time
– Offset of device time from
utc_off
UTC/GMT (without daylight time
correction)
– Daylight saving time
dst_state
state
0 – no daylight saving time
1 – daylight saving time
mode – On/Off
0 – Off
1 – On
– Time server IP
time_server_ip
address
sync_hour – Hour in day for time
server sync
– On/Off
server_status
– On/Off
mode
0 – Off
1 – On
time_server_ip – Time server IP
address
sync_hour – Hour in day for time
server sync
– On/Off
server_status
Hdbt_port_id:
HDBT port number
hdbt_mode:
HDBT mode
0-Transmitter
1-Receiver
Hdbt_port_id:
HDBT port number
hdbt_mode:
HDBT mode
0-Transmitter
1-Receiver
com_id – 1 to n (machine dependent)
– 9600 - 115200
baud_rate
– 5-8
data_bits
– Parity Type
parity
0 – No
1 – Odd
2 – Even
3 – Mark
4 – Space
stop_bits_mode – 1/1.5/2
serial_type – 232/485
0 – 232
1 – 485
– 485 termination state
485_term
0 – disable
1 – enable
(optional - this exists only when
serial_type is 485)
Set local time offset to 3
with no daylight-saving time:
#TIME-LOC3,0<CR>
Get local time offset from
UTC/GMT:
#TIME-LOC?<CR>
Set time server with IP
address of 128.138.140.44
to ON:
#TIME-
SRV1,128.138.140.44,
0,1<CR>
Get time server:
#TIME-SRV?<CR>
Set device in Transmitter
mode

#TXRX-MODE 1,0<CR>
Set device in Transmitter
mode

#TXRX-MODE? 1,<CR>
Set baud rate to 9600, 8
data bits, parity to none and
stop bit to 1:
#UART9600,8,node,1<C
R>
79
