Setting Analog Audio Output Volume Level
To set the audio output volume level:
1. Go to the Routing Operation page.
2. Next to Analog output volume (dB) click
3. Set the audio volume level:
▪
using the slider next to Analog output volume (dB, from -80 to 20), or
▪
enter the audio output volume in the text box.
Audio level is set.
Video and USB host inputs are routed to the outputs and USB devices.

Setting AV Properties

•
Setting the Auto-Switching Policy
•
Settings AV Signal Properties
•
Managing EDID
Setting the Auto-Switching Policy
This section is applicable for Receiver side only.
To set the AV auto-switching policy:
1. Go to the Auto switching tab.
2. Next to the Selection Mode drop-down box, select the auto switching policy: Manual,
Last Connected or Priority.
AV auto-switching policy is set.
To change AV Host Input Priorities:
1. Go to the Auto switching tab.
2. Next to the Selection Mode drop-down box, select Priority.
EXT3-21-XR-TR – Using Embedded Web Pages
Figure 18: Setting Audio Output Volume Level
on page 27.
on page 28.
on page 29.
.
