NET-IP
Set IP address.
For proper settings
consult your network
administrator.
NET-IP?
Get IP address.
NET-MAC?
Get MAC address.
For backward
id
compatibility, the
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
NET-MASK
Set subnet mask.
For proper settings
consult your network
administrator.
NET-MASK?
Get subnet mask.
PASS Set password for login
level.
The default
password is an empty
string.
PASS?
Get password for login
level.
The default
password is an empty
string.
PRG-ACTION
Add new user
command.
Programs matrix
action as a response
for external event
(programmable button
pressed).
PRG-ACTION? Add new user
command.
Programs matrix
action as a response
for external event
(programmable button
pressed).
EXT3-21-XR-TR – Protocol 3000
COMMAND
#NET-IPip_address<CR>
FEEDBACK
~nn@NET-IPip_address<CR><LF>
COMMAND
#NET-IP?<CR>
FEEDBACK
~nn@NET-IPip_address<CR><LF>
COMMAND
#NET-MAC?id<CR>
FEEDBACK
~nn@NET-MACid,mac_address<CR><LF>
COMMAND
#NET-MASKnet_mask<CR>
FEEDBACK
~nn@NET-MASKnet_mask<CR><LF>
COMMAND
#NET-MASK?<CR>
FEEDBACK
~nn@NET-MASKnet_mask<CR><LF>
COMMAND
#PASSlogin_level,password<CR>
FEEDBACK
~nn@PASSlogin_level,password<CR><LF>
COMMAND
#PASSlogin_level <CR>
FEEDBACK
~nn@PASSlogin_level,password<CR><LF>
COMMAND
#PRG-ACTIONcommandNum,type,name,command<CR>
FEEDBACK
~nn@PRG-ACTIONcommandNum,type,name,command<CR><LF>
COMMAND
#PRG-ACTION?commandNum<CR>
FEEDBACK
~nn@PRG-ACTIONcommandNum,type,name,command<CR><LF>
Kramer Electronics Ltd.
ip_address – Format: xxx.xxx.xxx.xxx
ip_address – Format: xxx.xxx.xxx.xxx
– Network ID–the device network
id
interface (if there are more than one).
Counting is 0 based, meaning the
control port is '0', additional ports are
1,2,3....
mac_address – Unique MAC address.
Format: XX-XX-XX-XX-XX-XX where X
is hex digit
– Format: xxx.xxx.xxx.xxx
net_mask
– Format: xxx.xxx.xxx.xxx
net_mask
– Level of login to set
login_level
(End User or Administrator).
– Password for the
password
login_level. Up to 15 printable ASCII
chars
login_level – Level of login to set
(End User or Administrator).
password – Password for the
login_level. Up to 15 printable ASCII
chars
– Command number 0 to
commandNum
4
type – External programmable button
cec
name – Bitmap representing
– External programmable
command
button ID
– Command number
commandNum
0 – Input
1 – Output
– External programmable button
type
ID
– Bitmap representing
name
– External programmable
command
button ID
Set the IP address to
192.168.1.39:
#NET-
IP192.168.001.039<CR
>
Get the IP address:
#NET-IP?<CR>
#NET-MAC?id<CR>
Set the subnet mask to
255.255.0.0:
#NET-
MASK255.255.000.000<
CR>
Get the subnet mask:
#NET-MASK?<CR>
Set the password for the
Admin protocol permission
level to 33333:
#PASSadmin,33333<CR>
Get the password for the
Admin protocol permission:
#PASS?admin<CR>
Add a new user command:
#PRG-
ACTION1,3,1,0<CR>
Add a new user command:
#PRG-
ACTION?0,3,1,0<CR>
