LOGIN
Set protocol
permission.
The permission
system works only if
security is enabled
with the "SECUR"
command.
LOGIN allows the user
to run commands with
an End User or
Administrator
permission level.
When the permission
system is enabled,
LOGIN enables
running commands
with the User or
Administrator
permission level
When set, login must
be performed upon
each connection
It is not mandatory to
enable the permission
system in order to use
the device
In each device, some
connections allow
logging in to different
levels. Some do not
work with security at
all.
Connection may
logout after timeout.
LOGIN?
Get protocol
permission state.
The permission
system works only if
security is enabled
with the "SECUR"
command.
LOGIN allows the user
to run commands with
an End User or
Administrator
permission level.
When the permission
system is enabled,
LOGIN enables
running commands
with the User or
Administrator
permission level
When set, login must
be performed upon
each connection
It is not mandatory to
enable the permission
system in order to use
the device
In each device, some
connections allow
logging in to different
levels. Some do not
work with security at
all.
Connection may
logout after timeout.
LOGOUT
Cancel current
permission level.
Logs out from End
User or Administrator
permission levels to
Not Secure.
MODEL?
Get device model.
NAME Set machine (DNS)
name.
The machine name
is not the same as the
model name. The
machine name is used
to identify a specific
machine or a network
in use (with DNS
feature on).
EXT3-21-XR-TR – Protocol 3000
COMMAND
#LOGINlogin_level,password<CR>
FEEDBACK
~nn@LOGINlogin_level,passwordok<CR><LF>
or
~nn@LOGINerr004<CR><LF>
(if bad password entered)
COMMAND
#LOGINlogin_level <CR>
FEEDBACK
~nn@LOGINlogin_level,passwordok<CR><LF>
or
~nn@LOGINerr004<CR><LF>
(if bad password entered)
COMMAND
#LOGOUT<CR>
FEEDBACK
~nn@LOGOUTok<CR><LF>
COMMAND
#MODEL?<CR>
FEEDBACK
~nn@MODELmodel_name<CR><LF>
COMMAND
#NAMEmachine_name<CR>
FEEDBACK
~nn@NAMEmachine_name<CR><LF>
Kramer Electronics Ltd.
login_level – Level of permissions
required (User or Admin)
– Predefined password (by
password
PASS command). Default password is
an empty string
– Level of permissions
login_level
required (User or Admin)
– Predefined password (by
password
PASS command). Default password is
an empty string
or NO SECURE if authentication is
removed.
– String of up to 19
model_name
printable ASCII chars
– String of up to 15
machine_name
alpha-numeric chars (can include
hyphen, not at the beginning or end)
Set the protocol permission
level to Admin (when the
password defined in the
PASS command is 33333):
#LOGINadmin,33333<CR
>
Get the protocol permission
level to Admin:
#LOGIN?admin<CR>
#LOGOUT<CR>
Get the device model:
#MODEL?<CR>
Set the DNS name of the
device to room-442:
#NAMEroom-442<CR>
