Function Description
EDID-AUDIO?
Get audio capabilities
for EDID.
EDID-CD Set EDID color space.
Setting
command
might change
the current
EDID.
EDID-CS? Get EDID color
space.
Setting
command
might change
the current
EDID.
EDID-DC
Force removal of deep
color on EDID or
leaving it as in the
original EDID.
EDID-DC? Get deep color status
on EDID.
ETH-PORT
Set Ethernet port
protocol.
If the port number
you enter is already in
use, an error is
returned.
The port number must
be within the following
range: 0-(2^16-1).
ETH-PORT?
Get Ethernet port
protocol.
If the port number
you enter is already in
use, an error is
returned.
The port number must
be within the following
range: 0-(2^16-1).
EXT3-21-XR-TR – Protocol 3000
Syntax
COMMAND
#EDID-AUDIO?<direction_type>.<port_format>.<port_ind
ex>. <signal_type>. <index><CR>
FEEDBACK
~nn@EDID-AUDIOaudio_format<CR><LF>
COMMAND
#EDID-CSinput_id,cs_mode<CR>
FEEDBACK
~nn@EDID-CSinput_id,CS_mode<CR><LF>
COMMAND
#EDID-CS?input_id<CR>
FEEDBACK
~nn@EDID-CSinput_id <CR><LF>
COMMAND
#EDID-DCin_index,deep_color_state<CR>
FEEDBACK
~nn@EDID-DCin_index,deep_color_state<CR><LF>
COMMAND
#EDID-DC?in_index <CR>
FEEDBACK
~nn@EDID-DCin_index,deep_color_state<CR><LF>
COMMAND
#ETH-PORTport_type,port_id<CR>
FEEDBACK
~nn@ETH-PORTport_type,port_id<CR><LF>
COMMAND
#ETH-PORT?port_type<CR>
FEEDBACK
~nn@ETH-PORTport_type,port_id<CR><LF>
Kramer Electronics Ltd.
Parameters/Attributes
The following attributes comprise the
signal ID:
▪ <direction_type> – Direction of
the port:
o IN – Input
o OUT – Output
▪ <port_format> – Type of signal
on the port:
o HDMI
o ANALOG_AUDIO
o USB_C
▪ – The port number
<port_index>
as printed on the front or rear
panel
▪ <signal_type> – Signal ID
attribute:
o AUDIO
▪ – Indicates a specific
<index>
channel number when there are
multiple channels of the same
type
audio_format – Audio block added to
EDID:
0 – Auto
1 – LPCM 2CH
2 – LPCM 6CH
3 – LPCM 8CH
4 – Bitstream
5 – HD
– Indicates a specific input
Input_id
number to change EDID
–
CS_color_mode
0 –RGB only
1 – RGB + YUV444
2 – RGB + YUV422
3– RGB + YUV444 + YUV422
4– auto / original config
– Indicates a specific input
Input_id
number to change EDID
– Number that indicates the
in_index
specific input:
1 – Input 1
2 – Input 2
–
deep_color_state
0 – Don't change
1 – Remove deep color
– Number that indicates the
in_index
specific input:
1 – Input 1
2 – Input 2
deep_color_state –
0 – Don't change
1 – Remove deep color
port_type – TCP/UDP
port_id – TCP/UDP port number
(0 – 65535)
– TCP/UDP
port_type
– TCP/UDP port number
port_id
(0 – 65535)
Example
Get HDMI IN 2 audio
capabilities for EDID:
#EDID-AUDIO?in.hdmi.
2.audio.1,2<CR>
Set HDMI IN 3 EDID color
space to force RGB
(enabled):
#EDID-CS3,0<CR>
Get EDID color space mode
:
on input 2
#EDID-CS?2<CR>
Remove deep color on
EDID for input 1.
#EDID-DC1,1<CR>
Get deep color state on
EDID for input 2.
#EDID-DC?2<CR>
Set the Ethernet port
protocol for TCP to 12457:
#ETH-PORTTCP,12457<C
R>
Get the Ethernet port
protocol for UDP:
#ETH-PORT?UDP<CR>
