Operating via Ethernet

•
Directly to the PC using a crossover cable (see
PC on page 17).
•
Via a network switch or router, using a straight-through cable (see
Port via a Network
If you want to connect via a router and your IT system is based on IPv6, speak to your IT
department for specific installation instructions.
Connecting Ethernet Port Directly to a PC
You can connect the Ethernet port of
using a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying
with the factory configured default IP address.
After connecting
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
EXT3-21-XR-TR – Operating and Controlling EXT3-21-XR-TR
Hub on page 19).
EXT3-21-XR-TR
EXT3-21-XR-TR to the Ethernet port, configure your PC as follows:
Figure 6.
Figure 6: Local Area Connection Properties Window
Connecting Ethernet Port Directly to a
Connecting Ethernet
directly to the Ethernet port on your PC
EXT3-21-XR-TR
