Kramer EXT3-C-XR-TR User Manual page 77

NAME?
Get machine (DNS)
name.
The machine name
is not the same as the
model name. The
machine name is used
to identify a specific
machine or a network
in use (with DNS
feature on).
NAME-RST
Reset machine (DNS)
name to factory
default.
Factory default of
machine (DNS) name
is "KRAMER_" + 4 last
digits of device serial
number.
NET-CONFIG
Set a network
configuration.
Parameters
[DNS1]
and
[DNS2]are optional.
For Backward
id
compatibility, the
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
If the gateway
address is not
compliant to the
subnet mask used for
the host IP, the
command will return
an error. Subnet and
gateway compliancy
specified by RFC950.
NET-CONFIG?
Get a network
configuration.
Parameters
[DNS1]
and
[DNS2]are optional.
For Backward
id
compatibility, the
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
If the gateway
address is not
compliant to the
subnet mask used for
the host IP, the
command will return
an error. Subnet and
gateway compliancy
specified by RFC950.
NET-DHCP?
Get DHCP mode.
For Backward
id
compatibility, the
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
NET-GATE Set gateway IP.
A network gateway
connects the device
via another network
and maybe over the
Internet. Be careful of
security issues. For
proper settings consult
your network
administrator.
NET-GATE? Get gateway IP.
A network gateway
connects the device
via another network
and maybe over the
Internet. Be aware of
security problems.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#NAME?<CR>
FEEDBACK
~nn@NAMEmachine_name<CR><LF>
COMMAND
#NAME-RST<CR>
FEEDBACK
~nn@NAME-RSTok<CR><LF>
COMMAND
#NET-CONFIGnetw_id,net_ip,net_mask,gateway,[dns1],[d
ns2]<CR>
FEEDBACK
~nn@NET-CONFIGnetw_id,net_ip,net_mask,gateway<CR><LF
>
COMMAND
#NET-CONFIGnetw_id,net_ip,net_mask,gateway,[dns1],[d
ns2]<CR>
FEEDBACK
~nn@NET-CONFIGnetw_id,net_ip,net_mask,gateway<CR><LF
>
COMMAND
#NET-DHCP?netw_id<CR>
FEEDBACK
~nn@NET-DHCPnetw_id,dhcp_state<CR><LF>
COMMAND
#NET-GATEip_address<CR>
FEEDBACK
~nn@NET-GATEip_address<CR><LF>
COMMAND
#NET-GATE?<CR>
FEEDBACK
~nn@NET-GATEip_address<CR><LF>
Kramer Electronics Ltd.
machine_name – String of up to 15
alpha-numeric chars (can include
hyphen, not at the beginning or end)
– 0
netw_id
– Network IP
net_ip
– Network mask
net_mask
gateway – Network gateway
– 0
netw_id
– Network IP
net_ip
net_mask – Network mask
gateway – Network gateway
– Network ID–the device
netw_id
network interface (if there are more
than one). Counting is 0 based,
meaning the control port is '0',
additional ports are 1,2,3....
dhcp_state –
0 – Do not use DHCP. Use the IP set
by the factory or using the net-
ip or net-config command.
1 – Try to use DHCP. If unavailable,
use the IP set by the factory or
using the net-ip or net-
config command.
– Format: xxx.xxx.xxx.xxx
ip_address
ip_address – Format: xxx.xxx.xxx.xxx
Get the DNS name of the
device:
#NAME?<CR>
Reset the machine name
(S/N last digits are 0102):
#NAME-
RSTkramer_0102<CR>
Set the device network
parameters to IP address
192.168.113.10, net mask
255.255.0.0, and gateway
192.168.0.1:
#NET-CONFIG0,192.168
.113.10,255.255.0.0,1
92.168.0.1<CR>
Get the device network
parameters:
#NET-CONFIG?0<CR>
Get DHCP mode for port 1:
#NET-DHCP?1<CR>
Set the gateway IP address
to 192.168.0.1:
#NET-
GATE192.168.000.001<
CR>
Get the gateway IP address:
#NET-GATE?<CR>
75
