I/O control commands (converted from the client received IP messages) to the I/O
controlled connected devices and distributes their received detected triggers to all
connected clients.
(see Setting Control Gateway Properties
Flexible Remote Buttons Control
Remote contact-closure buttons can be connected to the I/O ports, for easy end user control
of device functions by button press and release operation. Flexible configuration of button
press/release actions and latching (default) or momentary operation mode, enable simple and
custom control according to user needs.
(see Configuring Remote Buttons
EXT3-21-XR-TR Flexible Powering
The EXT3-21-XR-TR, when connected to the power supply, can supply power to the
connected transmitter / receiver via HDBT. The EXT3-21-XR-TR, can also accept power from
either LAN or HDBT.
Single Device Operates as Either Tx or Rx
Using the front panel button or the embedded webpage, enables the
easily set to operate either as a transmitter (Tx) or receiver (Rx).
(see Setting Extender Operation Modes

Using Front and Rear Panel Buttons

EXT3-21-XR-TR
•
Switching between Rx↔Tx mode.
Switching between modes initiates Factory Reset.
•
Selecting an INPUT, when in Rx mode.
•
Turning the display on or off via the DISPLAY ON or sending on or off commands that
are configured via the UI (see
control) on page 50).
•
Resetting device to its factory settings (for additional instructions on resetting and
resetting device (see
EXT3-21-XR-TR – Operating and Controlling EXT3-21-XR-TR
on page 49).
front panel buttons enable the following actions:
Associating Commands to DISPLAY ON/OFF (Custom
Resetting and Restarting Device
on page 39).
on page 33)
on page 34).
