Routing Operations

This section details the following actions:
•
Routing an Input to an Output
•
Setting Analog Audio Output Volume Level
Routing an Input to an Output
When routing any of the inputs to the output, you can set both inputs to route the AV signal
together with the USB signal (USB follows video coupled routing) or to independently route
each individual signal.
Routing cross-point grid for Tx and Rx operation modes (see
Routing on page 24), enable either coupled or independent AV and USB signals routing, as
follows:
Extender AV Routing
Operation
Mode
Tx Inputs: 1xHDMI
Outputs: 1xHDBT, Mirrored 1xHDMI
Rx Inputs: 1xHDMI, 1xHDBT
Outputs: 1xHDMI
Active Host connects to all local and remote devices.
EXT3-21-XR-TR – Using Embedded Web Pages
on page 23.
on page 27.
USB Host Routing
Input Hosts: 1xUSB-B (local) + 1xHDBT (remote Rx)
Routing between local and remote active USB
Hosts.
Output Devices: 3xUSB-A (local) + Rx USB devices
(remote)
USB local devices are always connected to active
Host. Remote USB devices connection to local
active Host is configurable (see
(Figure 15).
Input Hosts: 1xUSB-B (local) + 1xHDBT (remote Tx)
Routing between local and remote active USB
Hosts.
Output Devices: 3xUSB-A (local) + Tx USB devices
(remote)
USB local devices are always connected to active
Host. Remote USB devices connections to local
active Host is configurable (see
(Figure 15).
