Kramer EXT3-C-XR-TR User Manual page 75

IR-STOP
Send IR stop
command to port.
LABEL
Set input/output label
LABEL?
Get input/output label
LOCK-EDID Lock last read EDID.
LOCK-EDID?
Get EDID Lock status.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#IR-STOPir_index,sn_id,cmd_name<CR>
FEEDBACK
~nn@IR-STOPir_index,sn_id,cmd_name,ir_status<CR><LF>
COMMAND
#LABELio_mode,io_index,switch,label_txt<CR>
FEEDBACK
~nn@LABELio_mode,io_index,switch,label_txt<CR><LF>
COMMAND
#LABEL?io_mode,io_index,switch,label_txt<CR>
FEEDBACK
~nn@LABELio_mode,io_index,switch,label_txt<CR><LF>
COMMAND
#LOCK-EDIDin_index,lock_mode<CR>
FEEDBACK
~nn@LOCK-EDIDin_index,lock_mode<CR><LF>
COMMAND
#LOCK-EDID?in_index <CR>
FEEDBACK
~nn@LOCK-EDIDin_index,lock_mode<CR><LF>
Kramer Electronics Ltd.
ir_index – Number that indicates the
specific ir port:
1-N (N= the total number of inputs)
* - broadcasts to all ports
– Serial number of command for
sn_id
flow control and response commands
from device
– String: IR command name
cmd_name
limited to 15 chars. Controlling device
must send the correct name (white
space or commas forbidden)
– IR Status
ir_status
0 – Sent (no error)
1 – Stop
2 – Done
3 – Busy
4 – Wrong Parameter
5 – Nothing to Stop
6 – Start
7 – Timeout
8 – Error
– Number that indicates
io_ mode
the specific input:
0 – Input
1 – Output
– Number that indicates the
io_index
specific input:
For inputs –
1 – USB-C IN 1
2 – HDMI IN 2
3 – HDMI IN 3
For output
1 – HDMI output
– 0
switch
– Custom label string
label_txt
between 1 and 32 (at least one
character and not bigger than 32).
io_mode – Number that indicates the
specific input:
0 – Input
1 – Output
– Number that indicates the
io_index
specific input:
For inputs –
1 – USB-C IN 1
2 – HDMI IN 2
3 – HDMI IN 3
For output
1 – HDMI output
– 0
switch
– Custom label string
label_txt
between 1 and 32 (at least one
character and not bigger than 32).
label string
– Number that indicates the
in_index
specific input:
1 – USB-C IN
2 – HDMI IN
lock_mode – On/Off
0 – Off unlocks EDID
1 – On locks EDID
– Number that indicates the
in_index
specific input:
1 – USB-C IN
2 – HDMI IN
– On/Off
lock_mode
0 – Off unlocks EDID
1 – On locks EDID
Send IR stop command to
IR Port 2:
#IR-
STOP2,1,power<CR>
Set the HDMI input label on:
#LABEL0,2,0,hdmi<CR>
Get the HDMI input label:
#LABEL?0,2,0,hdmi<CR
>
Lock the last read EDID
from input 2:
#LOCK-EDID2,1<CR>
Get input 2 Lock EDID
status:
#LOCK-EDID?2<CR>
73
