Setting Control Gateway Properties

This section details the following actions:
•
Setting Serial Port Properties
•
Configuring I/O (GPIO) Ports
•
Defining and Testing Commands via Action Editor
•
Configuring Remote Buttons
•
Setting Relays
•
Associating Commands to DISPLAY ON/OFF (Custom control)
•
Setting IR Port Properties
Setting Serial Port Properties
EXT3-21-XR-TR
•
Serial Port 1 – Panel RS-232 port
•
Serial Port 2 – HDBT RS-232 channel
The serial ports are serving for one of the following:
•
RS-232 extension – From panel port, via HDBT RS-232 channel, to control a peripheral
connected to the HDBT paired unit RS-232 port.
•
External peripheral IP control – Remote IP control of port-connected peripheral, via
extender built-in control gateway.
•
Extender management and control – Device service and control using P3000 commands
(serial port 1 only)
EXT3-21-XR-TR
•
Extending the RS-232 via the EXT3-21-XR-TR
•
Controlling an External Device
•
Controlling the Display
Extending the RS-232 via the
Setting the HDBT Extension Mode:
Set the HDBT as an RS-232 extender to control the remote peripheral device.
EXT3-21-XR-TR – Using Embedded Web Pages
on page 39.
on page 44.
on page 49.
on page 49.
on page 52.
has two RS-232 ports:
enables configuring the RS-232 port in one of the following ways:
on page 42.
on page 43.
EXT3-21-XR-TR
on page 48.
on page 50.
on page 39.
