Specifications - Deviser S7200 User Manual

Part IV: System Functions

Specifications

Spectrum Analysis
Frequency Range
Frequency Span
Frequency Step
Resolution Bandwidth (‐3dB)
Level Measurement Range
Measurement Accuracy
Reference Level
Markers
Analog TV Measurement
Standards
Color Standards
Frequency Step
Hum Measurement
C/N
Level Measurement Range
Measurement Accuracy
Level Resolution
DVB‐T/H Measurement
Frequency Range
Modulation Type
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
DVB‐T2 Measurement
Frequency Range
Modulation Type
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
146
4 ~ 1220 MHz (Cable)
950 ~ 2150 MHz (Satellite)
0 ~ 1216 MHz, full span
1 kHz
30kHz, 100kHz, 300kHz, 1 MHz, 3 MHz
‐50 ~ +60dBmV (TV)
‐30 ~ +60dBmV (Satellite)
< 1.5dB
‐30 ~ +60dBmV
2 vertical markets
B/G, I, D/K, L/L', M/N
NTSC, PAL, SECAM
10kHz
1 ~ 15%
> 50dB
‐30 ~ +60dBmV
< 1.5dB
0.1dB
42 ~ 1002 MHz
QPSK, 16 QAM, 64 QAM
‐35 ~ +50dBmV
0.1dB
±1.5dB (C/N >20dB)
>35dB
±2.0dB
42 ~ 1002 MHz
QPSK, 16 QAM, 64 QAM, 256 QAM
‐35 ~ +50dBmV
0.1dB
±1.5dB (C/N >20dB)
>38dB
±2.0dB
ATSC Measurement
Modulation Type
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
ISDB‐Tb Measurement
Modulation Type
Modulation Bandwidth
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
CBER
VBER
DVB‐C Measurement
Frequency Range
Modulation Type
Symbol Rate
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
BER
DVB‐C2 Measurement
Power Level Range
Power Level Accuracy
Guard Interval
Bandwidth
Spectrum Inversion
PLP Code Rates
PLP Constellation
Data Slices
Cell / Network / CS System ID
J.83 Annex B only available on model S7200-ATSC.
*
8VSB
‐35 ~ +50dBmV
0.1dB
±1.5dB (C/N >20dB)
>40dB
±2.0dB
DQPSK, QPSK, 16 QAM, 64 QAM
6 MHz
‐35 ~ +50dBmV
0.1dB
±2.0dB (C/N >20dB)
>40dB
±2.0dB
1E‐1 ~ 1E‐5
1E‐1 ~ 1E‐7
42 ~ 1002 MHz
16/32/64/128/256 QAM
*
ITU‐T J.83 Annex A, B , C
1.8 ~ 7.0 MS/s
‐30 ~ +50dBmV
0.1dB
±1.5dB (C/N >20dB)
>42dB
±2.0dB
1E‐3 ~ 1E‐9
‐30 ~ +50dBmV
±1.5dB (C/N >20dB)
1/64, 1/128
6 MHz and 8 Mhz
Auto
2/3, 3/4, 4/5, 5/6, 8/9, 9/10
16, 64, 256, 1024, 4096 QAM
Support type 1 & 2, up to 7.61 MHz
Detected from Transmitter Station
