1-6.2 Charging the Unit
Please follow the following steps to charge the unit:
1. Place the instrument standing up with the screen facing you, then insert the DC connector into the VDC
power inlet at the top left of the instrument.
2. When the charging indicator displays a gradually-filling battery icon in the status bar on the screen, the
instrument is charging. The LED next to the power button indicates status: green means fully charged,
red means charging in progress, and red and green flickering indicates no battery or abnormal battery.
3. Once the instrument reaches full charge, t is recommended to charge for one additional hour to help
extend the operation time. After charging, unplug the DC connector, and then pull out the AC adaptor
from the outlet.
NOTE: Charge the instrument fully before using it for the first time.
Adapter Specifications
Model No.
AC input
DC output
FSP060-DBAE1
100-240V~, 1.5A, 50-60Hz
12.0V 5A MAX
