Chapter 20 — Specifications
Frequency
Frequency Range
Resolution
Measurement Speed
Reflection
DTF
Data Points
Measurement Accuracy
Corrected Directivity 42 dB (typical, after standard OSL calibration)
38 dB (typical, after eCAL calibration)
Output Power
0 dBm (Nominal)
Interference Immunity
On-channel
Off-channel
Measurements
Return Loss
VSWR
Cable Loss
DTF Range (Distance)
Connectors (Reflection/RF Out)
RF Out
RF Out Damage Level
Connectivity
USB host
USB client
LAN
2 MHz – 4.4 GHz
0.5 kHz
< 1.0 mS/point
< 1.25 mS/point
130, 259, 517, 1033, 2065
+18 dBm, >1 MHz of carrier frequency
+13 dBm, ±10 kHz of carrier frequency
0 to 60dB (Resolution 0.01 dB)
1:1 to 65:1
0 to 30 dB (Resolution 0.01 dB)
1500 meters (4921 feet)
Type N, female, 50Ω
25 dBm, ± 50 VDC
USB 2.0 Type A
5-pin mini-B
(connect to PC for data transfer)
RJ45 10M/100M LAN Ethernet Port
E7000L SitePROFILER
Handheld Cable/Antenna Analyzer
Display
Type/Size
Data Storage
Internal
External
Battery
Type
Operation
Environmental
Operating Temperature -10°C to +55°C
Storage Temperature
Maximum Huminity
Shock
Altitude
EMC
European EMC
AC Power
AC Adapter Output
AC Adapter Input
Size & Weight
Size
Weight
For a list of software-enabled measurement options
available from Deviser, please see Section 1-3.
For a list of compatible accessories, please see
Section 1-4.
TFT LCD / 7.0" (800x480)
1 GB, >2000 saved measurement files
Limited by size of USB flash drive
Li-Ion, 7.4V, 7.5AH
TYP.> 8.0 hrs, continuous
-40°C to +80°C
95% RH (non-condensing) @ 40°C
Mil-PRF-28800F Class
4600 meters, operating and non-
operating
IEC/EN 61326-1:2006
11-14 VDC
100-240 VAC, 50-60 Hz
245mm x 190mm x 75mm
(9.64in x 7.48in x 2.95in)
2 kg (4.4 lbs)
