13-4.2 DiSEqC
In the 1990s, EUTELSAT (European Telecommunication Satellite Organization) and Philips jointly developed the
DiSEqC (Digital Satellite Equipment Control) technology. Today, several versions of DiSEqC exist. All versions
are backwards-compatible.
The DiSEqC menu is a scrolling list of LNB commands. Tap a
command to transmit it. (If an error occurs, make sure that
"LNB Power" is set correctly; see subsection 13-4.1 above.)
If a highlighted line contains the
column, you can customize the value using the Left/Right
arrow keys.
Satellite IF Signal Switch operation principle
Power
Auto According to satellite auto-setup
13V Vertical polarization, low LO
18V Horizontal polarization, low LO
13V+22K Vertical polarization, high LO
18V+22K Horizontal polarization, high LO
24V 24V
The S7200 supports DiSEqC versions 1.0, 1.1, 1.2, and 2.x.
icon in the right-hand
