Deviser S7200 User Manual page 136

Part IV: System Functions
13-4.4 dCSS
The dCSS (digital Channel Stacking Switch) LNB can support several users on a single cable distribution
system by allocating specific user bands for each of them. Note that dCSS can only be used if your field
strength meter communicates using EN50494 (SATCR, UNICABLE) and EN50607 (dCSS, JESS, UNICABLE II)
standard protocols.
Using the dCSS function, the S7200 supports channel controls for up to 32 users. Users can set up channels
and install equipment. For the first use, in the dCSS tab, select Install to automatically search for compatible
channels. The external feed setting must then be activated (
the State field to Enable. (See below.) Use the scroll bars to view the full channel list.
UB‐2 Channel Enabled
Column
Enabled/Disabled
UserBand
Frequency (MHz)
Status
Position
PIN code
Used
Protect
136
dCSS Channel List
Description
Enabled channels have a check mark. If disabled, the channel cannot be used.
User channel ID, such as UB-2.
The frequency of the selected channel. Depends on device parameters.
Active channels are shown as ON. Inactive channels are shown as OFF.
Set A or B
PIN used to lock the channel while in use. For example, if UB-2's PIN is 18 and "Protect" status is
"YES", other users must input the same PIN code or reboot the device in order to use this channel.
If YES, channel is already in use. If NO, channel is free and unoccupied.
If YES, another user is using this channel and has locked it with a PIN code. If NO, it is unlocked.
) in order to transmit dCSS commands. Set
UB‐2 Channel Disabled
