Part II: Settings and Measurements
Supported Analog TV Standards
TV standard
NTSC-M
PAL-M
PAL-B,D,G,H,I,K
PAL-N
Digital (DVB-C, -C2, -T2, T/H) & ATSC Channel Parameters
Channel serial number:
Channel name:
Channel status:
System rate:
Frequency:
Measure BW:
Modulation:
GI (Guard Interval): [¼ / ⅛ / 1/16 / 1/32]
FFT Mode:
Code Rate:
Hierarchy:
Cell ID:
SR (System Rate):
STD (Standard):
BER Statistical Time: The BER measurement time in BER statistical and auto test BER statistical functions.
NOTE: For Digital channels, the channel plan creator can tell the difference between Analog and
Digital, but not between DVB-C and DOCSIS. You will need to instruct your channel plan in the editor
mode on the 4th line in the channel edit window.
US and EU Default Symbol Rate for DVB-C and DOCSIS
On select models only.
*
26
Lines per frame
525
525
625
625
Edit with keypad
[Enable / Disable]
[50Hz / 60Hz]
Edit with keypad
Edit with keypad
[16QAM / 32QAM / 64QAM / 128QAM / 256QAM]
[2K / 8K]
[1/2 / 2/3 / 3/4 / 5/6 / 7/8]
[None / 1 / 2 / 4]
Enter number
The symbol rate is auto-configured according to the modulation type and standard. It
will set automatically once the modulation type and standard are selected. Users can
input values manually, ranging between 4.00MS/s ~ 7.00MS/s.
[J.83A / J.83B
/ J.83C / DOCSIS / EuroDOCSIS]
*
Standard and Modulation Type
ITU-T J.83 Annex A 64QAM
ITU-T J.83 Annex A 256QAM
ITU-T J.83 Annex B 64QAM
ITU-T J.83 Annex B 256QAM
ITU-T J.83 Annex C 64QAM
ITU-T J.83 Annex C256QAM
DOCSIS 64QAM
DOCSIS 256QAM
EuroDOCSIS 64QAM
EuroDOCSIS 256QAM
Field frequency
Color encoding method
60Hz
60Hz
50Hz
50Hz
Symbol Rate
Bandwidth
6.952MS/s
6.952MS/s
5.057MS/s
5.361MS/s
5.274MS/s
5.274MS/s
5.057MS/s
5.361MS/s
6.952MS/s
6.952MS/s
NTSC
NTSC
PAL
PAL
8MHz
8MHz
6MHz
6MHz
6MHz
6MHz
6MHz
6MHz
8MHz
8MHz
