DiSEqC Version Guide
Basic DiSEqC instruction set. Includes Tone Burst function and four LNB controls. Can
transmit various commands: polarization, high & low bands, antenna position, etc.
Unidirectional system, meaning that the receiver sends instructions to the
corresponding system module. Instructions are only sent once, not repeated..
Based on v1.0, v1.1 adds the C band LNB control function and four custom
functions. Transmits instructions with Improved accuracy by allowing the same
instruction to be sent repeatedly.
Expansion of v1.1. Adds polar antenna remote control capability.
v2.0 is a bidirectional system otherwise similar to v1.0. System modules can both
receive instructions and respond to confirm successful execution. Receivers can
also use this response to detect existing modules.
Combines all functions of v1.1 and v2.0.
Expansion of v2.1. Adds polar antenna remote control capability.
DiSEqC Protocol Command List
Command
RESET
STANDBY
POWER ON
SAT A/B
POSITION A/B
OPTION A/B
OPT/POS
DiSEqC1.0 SWITCH
DiSEqC1.1 SWITCH
HALT
DISABLE LIMITS
SET LIMIT EAST
SET LIMIT WEST
DRIVE EAST SEC
DRIVE EAST STEPS
DRIVE WEST SEC
DRIVE WEST STEPS
STORE POSITION
GOTO POSITION
GOTO X.X°
GOTO 0
Description
Parameter
----
----
----
A/B
A/B
A/B
A-A/A-B/B-A/B-B
1 to 4
1 to 16
. ----
----
----
----
1 to 127
1 to 127
1 to 127
1 to 127
1 to 255
1 to 255
-80° to 80°
----
