Part IV: System Functions
14-1.2 Sort
As discussed, files are listed alphabetically by default. If you
wish to list files in a different order, press Sort to open the Sort
dialog (shown, right).
Highlight and select options with the arrow and Enter keys.
Place a check next to "File Name" to sort files alphabetically,
"File Date" to sort by timestamp, or "File Type" to sort by
format. Use the radio button to select Ascending or
Descending order.
When you have finished changing settings, tap OK to sort files
as specified.
14-1.3 Rename
To rename a particular file, highlight it and press Rename. Use the touchscreen keypad to enter the new
filename. (Only letters and numbers may be used. Special characters, including hyphens, slashes, periods,
and spaces, are not recognized. Uppercase and lowercase letters are valid.)
When finished, press Enter to confirm. Press Back once to recall the previous filename, or again to cancel the
operation.
14-1.4 Delete
When you no longer need one or more files, you can erase them from the S7200's internal hard drive.
Highlight files with the arrow keys and press Enter to select them. Delete will become available.
When you press Delete, you will be prompted to confirm the deletion. Press OK to erase the data, or Cancel
to go back. You may also wish to export existing data to an external USB storage drive first; see Section 14-2
for details.
14-2

Importing and Exporting Data

To export files to a USB storage device, first ensure the device is connected via the S7200's connector panel.
The USB icon will appear in the status bar. Use the arrow keys to highlight the desired file, press Enter to select
files to export, and then tap Export.
144
Upon transfer to USB, new directories will be automatically
created on the storage device. (If these folders already exist,
files will be copied to them as normal.)
Measurement data files will be placed in "S7200_file" and
screenshot / image files in "S7200_bmp". Data files will export
in CSV format, which can be opened with Microsoft Excel or
another spreadsheet software. The Toolbox PC software can
also review and analyze S7200 exported files.
