Specifications - Nice HySecurity SlideSmart DC Series Installation And Programming Manual

SlideSmart DC models, AC and solar
™
Standard
Solar
Gate Weight Max.
Gate Length Max.
Pull Force*
Rate of Travel
Duty Cycle
Horsepower
Drive
UPS Battery Backup
Cycles †
Temperature Rating
Operating Voltage
Input Voltage
Accessory Power
Communication
User Controls
Relays Two confi gurable user relays: 30VDC, 3A solid state and 250VAC, 10A electromechanical; Optional Hy8Relay™ for 8 additional relay outputs
Finish
ETL Listed (UL 325)
Cycle Tested
Warranty
* HySecurity manufacturers only reliable and powerful gate operators and provides an extra margin of power to be certain the gate works in adverse conditions. Some manufactures
overstate the length and weight capacity of their operators, but HySecurity rates conservatively. Note that our pull force ratings are substantial and that extra margin of power is part of
the HySecurity reputation for reliability.
** Speed setting cannot be confi gured to exceed 1 ft/s for Class I and II usage.
*** Not for residential use or applications intended to serve the general public.
† The actual number of gate cycles available from battery depends upon gate resistance to travel, cycle length, battery size, state of charge and health, ambient temperature, accessory
power draw and frequency of gate cycles during power outage.
To enable fully automatic operation, all SLIDE gate operators require a minimum of TWO monitored external entrapment protection sensors (one for each direction) to protect
entrapment zones in both the open and close direction of travel. Visit hysecurity.com/gatesafety for more information on UL 325 standards and gate safety.
Contact Information: Visit
part diagrams and more. Qualified Nice | HySecurity distributors are experienced and trained to assist in resolving
installation problems. For the name of a qualified distributor near you, call HySecurity at 800-321-9947. *Before
contacting your distributor or HySecurity Technical Support, obtain the serial number of your operator.
136 136
support.hysecurity.com
FAST
SlideSmart DC 10F
SlideSmart DCS 10F
1,000 lb (453 kg)
200 lb (90.7 kg)
1.75, 2 or 2.25 ft/s (53, 61 or 69 cm/s)
Open/Close speed set independently
Field confi gurable to fail open or secure when batteries deplete.
Standard battery backup gate travel: Two 8Ah batteries. Up to 4,000 ft (1,219 m) after AC power loss.
Extended battery backup gate travel: Two 50Ah batteries. Up to 25,000 ft (7,620 m) after AC power loss.
115V or 208-230V, 60/50 Hz. Solar: 24VDC solar panels †
Smart DC Controller with 70+ confi gurable settings. 32 character LCD display and 5 tact buttons or a PC using S.T.A.R.T. software.
Usage Class III, IV***
5 year w/product registration
support.hysecurity.com
40 ft (12 m)
Continuous
1/2 hp
Electromechanical
-13ºF to 158ºF (-25ºC to 70ºC)
24VDC
12VDC and 24VDC 1A each
USB, RS-232, RS-485.
Zinc plated chassis; molded polyethylene cover
500,000 cycles
5 year (7 year single-family residential) w/product registration
for Installation manuals, replacement part instructions,

SPECIFICATIONS

SlideSmart DC 15
SlideSmart DCS 15
1,500 lb (680 kg)
300 lb (136 kg)
0.75, 1 or 1.25 ft/s (23, 30 or 38 cm/s)**
Open/Close speed set independently
Usage Class I, II, III, IV**
