All the control device inputs listed in Table 11 are shown as a single input. The second wire is connected
to a Common Terminal Bus (1 - 8) on the Smart DC Controller board.
The Fire Department Open input is an exception and requires a +24VDC input as well as activation through
the Installer Menu. For convenience a +24VDC terminal is located next to the EMERG OPEN terminal.
See Figure 57. Note that programming in the User or Installer Menu is required for most connections.
Terminal Label/Input
No. Name
Common
1- 8
Terminals
Stop push
9
button*
Open push
10
button*
Close
11
button
Remote
Open
12
& Radio
Control**
Partial
13
Open
14 Sensor 2
15 Sensor 3
Free Exit
16 Vehicle
Detector
Block Free
Exit vehicle
17
detector or
Close Timer
Inside
Obstruction
18
Vehicle
Detector
74 74
support.hysecurity.com
Table 11. Smart DC Controller Board Inputs
Wire Connection
All user inputs are energized when connected
to common except Emergency Open.
Normally Closed (N.C.). input. Jumper to
Common if not being used.
Normally Open (N.O.) input. Not for radio
or remote access controls.
N.O. input. Connection for a close push-
button.
N.O. input. For radio/remote open or close
device - Access the User Menu and program
RO RADIO OPEN/CLOSE.
N.O. input. This input will cause the gate to
open to Partial Open position programmed
in the Installer Menu (7-32ft).
N.C. input. Connection of a Monitored
External Entrapment sensor. Type of sensor
used is programmable in Installer Menu (S2).
N.C. input. Connection of a Monitored
External Entrapment sensor. Type of sensor
used is programmable in Installer Menu (S3).
N.O. input. Connection for free exit vehicle
detector.
N.O. input. Free Exit is only disabled if Close
Limit Switch is tripped. If the gate is partially
opened, the Free Exit detector will trigger
the gate to open fully. The input can be
converted in the Installer Menu to alternately
disable the Close Timer.
N.O. input. Inside reversing loop.
SMART DC CONTROLLER
All inputs except Emergency
Open
Line of sight, external stop
button or 3-button station.
Line of sight, external open
button or 3-button station.
Line of sight, external close
button or 3-button station.
Remote access control or radio
controls
Supervised access controls
External entrapment sensors.
External entrapment sensors.
Vehicle detector, box type
connections for free exit loop.
If gate is partially opened, Free
Exit detector will trigger gate
to open fully. Input can be
converted in Installer Menu to
alternately disable Close Timer..
Vehicle detector, box type
connections inside reversing
loop.
Uses
