APPENDIX A - INSTALLATION CONFIGURATIONS
3.25
2.50
Chain to Gate
2.66
10.50
5.00
4.00
3.81
20.7
7.75
12.5
3.0
124 124
support.hysecurity.com
4.5 x 7
Conduit
Area
5.50
10.38
18.0
Post
Height
17.63 ID of
Post Mount Plate
NOTE: DRAWING IS NOT TO SCALE.
Figure 92. Post Mounted with Base Riser
If no batteries In Base Riser -
Conduit Area is 7"x9"
17.5
U-bolts provided for 4" OD pipe (slot allows for
3.5-4.5" OD pipe). For best results,
HySecurity recommends welding plate to posts.
4X .625
3.25
2.50
Chain to Gate
.72
6.0
