To designate what you want operator to do during
an AC power loss, access User Menu (see "User
Menu" on page 48 and Figure 43) and scroll
through items until AP (AC LOSS) display appears:
1. Use SELECT and NEXT buttons to navigate
and change number on display. Review Using
the "Using the Smart DC Controller Buttons
In Menu Mode" on page 45.
2. To exit User Menu, press MENU button. A gate
status appears in display indicating you have
returned to Run Mode.
AP 0 (AC LOSS)
UPS FAIL OPEN
OPEN CLOSE
PREV NEXT
Figure 44. AC Power Loss
NOTICE
If extremely low temperatures are expected,
set the contrast to a higher number.
STOP MENU RESET
SELECT
DISPLAY AND MENU OPTIONS

ADJUSTING THE DISPLAY CONTRAST

The display contrast can be adjusted from 1 to 9
to increase visibility and ease of use. It is set at the
factory to level 5. The text becomes darker as you
go up the scale.
To adjust the contrast (1 to 9), take the following
steps and see Figure 44:
1. At a gate status display, press the MENU
button twice. This accesses the User Menu and
the CLOSE TIMER display appears.
2. Press NEXT until the LCD CONTRAST display
appears.
3. Use the SELECT and NEXT buttons to navigate
and change the number on the display.
4. To exit the User Menu, press the MENU button.
A gate status appears in the display indicating
you have returned to Run Mode.
OPEN
PREV
Figure 45. LCD Contrast
LD 5
LCD CONTRAST
CLOSE STOP MENU RESET
SELECT
NEXT
