Table 10. Smart DC Controller - Installer Menu Functions
Ref. User Menu
No. Display
OS 5
OPEN SPEED
5
CS 5
CLOSE SPEED
6
FD 0 (OFF)
FACTORY DEFAULTS
7
DG 0 (OFF)
DUAL GATE
8
*NOTE: Use a 2-pair, twisted, shielded cable with one pair of wires used to connect A-A and B-B
terminals between the two boards. The other pair will connect the Common terminals. The shield
should then be grounded on only one end to one of the operators.
Setting Options
(Bold = Factory Menu Tasks and Explanations
Settings)
Designates how quickly gate
DC 15
opens. Options available differ
0 = 0.75 ft/s
depending on Operator Type (OT).
1 = 1.0 ft/s
SlideSmart has two operator types:
2 = 1.25 ft/s
OT15 ≤1.25ft/s and OT16 ≥ 1.75ft/s.
DC 10F
Settings higher than 1 are reserved
4 = 1.75 ft/s
for Usage Class 3 and 4.
5 = 2.0 ft/s
NOTE: SlideSmart DC15 = OT 15
6 = 2.25 ft/s
and SlideSmart DC10F = OT16.
Designates how quickly gate
DC 15
closes. Options available differ
0 = 0.75 ft/s
depending on Operator Type (OT).
1 = 1.0 ft/s
SlideSmart has two operator types:
2 = 1.25 ft/s
OT15 ≤1.25ft/s and OT16 ≥ 1.75ft/s.
DC 10F
Settings higher than 1 are reserved
4 = 1.75 ft/s
for Usage Class 3 and 4.
5 = 2.0 ft/s
NOTE: SlideSmart DC15 = OT 15
6 = 2.25 ft/s
and SlideSmart DC10F = OT16.
Globally restores all menu settings
back to new operator status. Select
0 = custom user setting 1 to return operator to
settings
factory defaults.
NOTE: If factory defaults are
1 = reload
factory default restored, the UL usage class,
settings handing, gate weight, and any
other modified menu settings will
need to be reprogrammed.
Configures gate operator as a
0 = solo
Primary or as a Secondary in a
operator
dual-gate installation. When you
1 = Secondary
assign one unit as Primary, you
unit must configure other as Secondary
through Installer Menu. This menu
2 = Primary unit
is also used to configure a Sally Port
system by setting one operator to
3 = Sally Port A
Sally Port A and the other to Sally
4 = Sally Port B
Port B.
DISPLAY AND MENU OPTIONS
DC Controller
Display
Connections
(N/A)
(N/A)
(N/A)
*Use shielded cable
to DUAL GATE input
terminals. Connect
D u a l G a t e C O M
(Gate 1) to Dual Gate
COM (Gate 2). Pair
wires: A - A, COM -
COM, and B - B. Dual
Gate wiring requires
3 wires.
