INSTALLING THE EXTENDED BATTERY
BACKUP KIT
Post-mounted
operator with
base extension
Posts not included
in kit
Figure 30. Unwired Extended Battery Backup Kit
HySecurity offers an extended DC power back
up option with two 50Ah batteries. Contact
HySecurity parts department to order extended
battery backup kit with base extension (P/N
MX002141).
To install the extended battery backup kit:
1. Turn off the DC and AC power switches.
2. Place the accessory tray on the studs inside
the base riser. See Figure 31.
3. To access the 8Ah batteries and disconnect
its wires, cut the two black wire ties and slide
the 8Ah batteries through the access window.
Another option is to remove the four screws
that hold the control box to the chassis. See
Figure 30.
Screws
50Ah
ba�eries
Accessory tray
Make sure both the left and right 8Ah DC
battery wires are disconnected. Never mix
battery sizes, types, or brands. HySecurity
strongly recommends that only sealed AGM
style batteries be used. If you plan to remove
the batteries from the operator, properly store
or discard them. Refer to Hazardous Materials
and Proper Disposal.
4. Place the two 50Ah batteries on the tray.
5. Attach the blue wire from the red terminal on
6. Run the red and black wires (disconnected
7. Using the wires supplied in the 50Ah battery kit,
(x4)
Control
Box
8Ah ba�ery
Figure 31. Batteries Access
DANGER
one 50Ah battery to the black terminal on other
50Ah battery.
from the 8Ah batteries) through the hole in
the support bracket.
attach the red wire to the red positive terminal
on the 50Ah battery. Connect its opposite end
to the red lead exiting the support bracket.
POWER
Wire
Access window
�es
8Ah ba�ery
