APPENDIX A - INSTALLATION CONFIGURATIONS
3.25
2.50
Chain to Gate
2.66
10.50
6.75 x 9
Conduit
Area
5.00
4.00
5.50
3.81
10.38
18.0
20.7
3.0
17.63 ID of
Post Mount Plate
Gate
Chain
17.5
U-bolts provided for 4" OD pipe (slot allows for
3.5-4.5" OD pipe. For best results,
HySecurity recommends welding plate to posts.
4X
.625
7.75
Chain Height
Post
Height
NOTE: DRAWING IS NOT TO SCALE.
Figure 91. Post Mounted
3.25
2.50
Chain to Gate
6.0
MX4505 Rev.H ©2022
