Ref. User Menu
No. Display
1
CT 0 (OFF)
CLOSE TIMER
HC 0 (OFF)
2
HOLD TO CLOSE
HO 0 (OFF)
HOLD TO OPEN
3
4
AP 0 AC LOSS
UPS FAIL OPEN
RO 0 (OFF)
5
RADIO OPEN/CLOSE
52 52
support.hysecurity.com
Table 9. Smart DC Controller - User Menu Functions
Setting Options
(Bold = Factory
Settings)
0 = Timer
disabled
1 second to 99
seconds
0 = off
1 = on
0 = off
1 = on
0 = UPS FAIL
OPEN
1 = UPS FAIL
CLOSE
2 = AUTO
OPEN
3 = NO CLOSE
TIMER
0 = off
1 = on
DISPLAY AND MENU OPTIONS
Menu Tasks and Explanations
Assign how many seconds before
open gate initiates automatic
closure. Keep setting at 0 if a hard-
wired, push-button control device
is being used.
NOTE: CLOSE TIMER display
does not appear when HOLD TO
CLOSE is set to 1.
Set to 0 to produce a gate closure
when a momentary signal is
transmitted. Set to 1 if a constant
hold to close signal, such as a push
button control, is being used. A
setting of 1 also deactivates the
automatic close timer and causes
its menu to disappear. You must
set HC to 1 to comply with UL 325
Type D protection. Refer to "Table
Notes:" on page 54"
Similar to HOLD TO CLOSE, but
configures OPEN push button for a
constant-hold function.
0 = Momentary open signal
1 = Constant hold to open push
button required. You must set HO
to 1 to comply with UL 325 Type D
protection. Refer to "Table Notes:"
on page 54"
Setting designates what action
gate performs during an AC power
loss. Refer to "Setting AC Power
Loss Gate Function" on page 49.
Configures radio input for open
only (0). If changed to setting 1
then adds capability for radio input
to close gate, but only when gate
is fully open.
Associated
DC Controller
Connections
Not applicable
(N/A)
COM
CLOSE
COM
OPEN
N/A.
COM
RADIO OPEN
