SETTING THE TIME AND DATE

A feature of the Smart DC Controller is its 24-hour,
365 day clock. Make sure it is set to the appropriate
time zone. An accurate time and date allows the
diagnostic log to date stamp operational data
which indicates when Alerts, Faults and Errors
occur. The log helps in troubleshooting and can
be viewed via a laptop connected to the USB or
RS232 port. For more information, refer to "Smart
DC Controller Troubleshooting" on page 99.
To set or adjust the time or date, take the following
steps:
1. At a gate status display, press the MENU
button twice. This accesses the User Menu and
the CLOSE TIMER display appears.
2. Press NEXT or PREV until the SET CLOCK
display appears.
3. Press SELECT. CL blinks.
4. Press NEXT or PREV to change the number
to 1.
5. Press SELECT to accept the display.
6. The date and time display appears. Use the
SELECT and NEXT buttons in the same manner
as before to adjust the date and time.
NOTICE
A date or time field must be blinking before it
can be changed.
7. To accept what appears on the date and time
display, press SELECT.
8. To exit the User Menu, press the MENU button.
NOTICE
A lithium coin battery, on the Smart DC
Controller board, supports the clock so the
date and time is retained even when the main
power is turned off. Replace the battery every
five years with a DL 2025, DL 2032 or CR 2025
or CR 2032 battery. Refer to "Clock Battery
Replacement" on page 118.
DISPLAY AND MENU OPTIONS
A gate status appears in the display indicating
you have returned to Run Mode.
HYSECURITY
GATE CLOSED
OPEN CLOSE STOP
PREV NEXT SELECT
CT 0 (OFF)
CLOSE TIMER
OPEN CLOSE STOP
NEXT SELECT
PREV
CL 1
SET CLOCK
OPEN CLOSE STOP
PREV NEXT SELECT
08/01/21
08/01/18
^^
OPEN CLOSE STOP
PREV NEXT SELECT
Figure 43. Setting Time and Date

SETTING AC POWER LOSS GATE FUNCTION

Setting in AC LOSS display determines what
action operator performs during an AC power loss.
Settings help reduce battery drain. You can choose
between four settings depending on customer
preferences. DC Solar Powered units can only be
set for AP0 or AP1.
1. Start at a gate
status display.
MENU RESET
2. To access the
User Menu,
press the MENU
button twice.
MENU RESET
3. Press NEXT until
the SET CLOCK
display appears.
Use the
navigational
buttons to select
1.
MENU RESET
4. Change the time
and date using
00:00
the NEXT and
SELECT buttons.
MENU RESET
