USER RELAYS - PROGRAMMING PROCEDURE

Smart DC Controller is able to interface with many types of external devices through the use of two user
programmable output relays. All user relay functions identified and described in Table 13 are accessible
in Installer Menu.
NOTICE
The User Relays will operate normally to less than 18VDC. The USER 2 RELAY is rated for DC only up
to 48V and does not have a N.C. (normally closed) connection.
Use the Smart DC Controller buttons to program the user relays according to the following steps:
1. Select and connect to the relay you wish to use on the Smart DC Controller board.
2. Access the Installer Menu and RL 1 or RL 2 display (depending on the relay you have connected).
3. Enter the appropriate function using the associated number (1 through 45) listed in the table.
Table 13. User-Programmable User Relays - Function Options
No. Name
1 Close limit output
Close limit pulse
2
output
3 Open limit output
Open limit pulse
4
output
Warn before/during
5
operate output
6 Gate Lock output
Gate forced open
7
output
82 82
support.hysecurity.com
Creates an interlock signal to another operator's interlock input, or
simply to indicate that gate is secure or not. Relay is released when fully-
closed limit switch is tripped. Relay is energized when fully-closed limit
is released. (Any open command energizes relay.)
Used in a sequenced system to command a second machine to close.
Generates a brief pulsed output that occurs when close limit is triggered.
Indicates gate is at full-open position. Output becomes active when an
open-limit is triggered and deactivates when open-limit is released or a
close command is received. Use this output for a traffic light.
Triggers a sequenced barrier arm gate operator to open. Generates a
brief pulsed-output when open-limit is triggered. An additional pulse is
also generated with any new open command even when gate is already
fully-opened.
Controls an external warning device. This output is active whenever
internal warn before operate buzzer is sounding but the relay output is
constant on. Activation of this relay is controlled by setting User Menu
for Warn Before Operate [bF].
Controls external solenoid locks or magnetic locks. In both directions of
travel, this output is activated about 7/10ths of a second before operator
starts moving the gate.
Activated if gate is forced off closed limit switch and operator is not
able to restore gate to full closed position within four seconds. Buzzer
resets itself in 30 seconds but relay stays active until gate receives a run
command.
SMART DC CONTROLLER
Description
