Display
Alert, Error or
Condition
ALERT 25
Coin Cell Battery
HYNET LOW
in HyNet is Low
BATTERY
ALERT 28 Battery
BATTERY Disconnected
DISCONNECTED from Board
P h o t o e y e i s
FAULT 2
missing or not
PHOTO EYE
working.
FAULT 3 Not used in
VOLTAGE SAG SlideSmart.
Smart DC
Controller has
detected there
FAULT 4 is no load on
GATE NO LOAD operator. Gate is
non-operational
while this fault is
triggered.
FAULT 5 Not used in
LIMIT FAILED SlideSmart.
Smart DC
Controller
tried 3 times to
FAULT 14 overcome stuck
STUCK GATE gate. Gate is
non-operational
while this fault is
triggered.
S m a r t
ERROR 1 C o n t r o l l e r
DIRECTION detects operator
ERROR r a n i n w r o n g
direction.
106 106
support.hysecurity.com
Table 16. Smart DC Controller - Troubleshooting
Description
Fault
Appears when a HyNet is connected
and reports that the internal battery of
the HyNet is low.
Dead or disconnected batteries
detected by SDC board. Operator
may still be functional if on AC power
but will not have battery backup. Was
Error 9 in pre-h5.57 software versions
This fault can only occur if monitored
photo eye function check fails. See
"Monitored External Entrapment
Sensors" on page 93 for details.
N/A
Possible causes:
• Motor wires disconnected.
• DC switch off.
• Check motor brushes.
N/A
Caused by broken gate hardware or
ice/snow buildup.
D C
Motor wiring.
TROUBLESHOOTING
Possible Causes Solutions
Replace the battery in
the HyNet
Replace or reconnect
batteries to the
controller.
Correct malfunctioning
photo eye.
N/A
1. Check DC motor
wires. Check motor
brushes.
2. Turn DC power
switch on.
3. Press RESET to clear
fault.
N/A
1. Check and correct
gate hardware as
required.
2. Press RESET to clear
fault.
1. Check motor wiring
and correct, as
needed.
2. Press RESET to clear
fault.
