Hyke HK7024 HK7224 Programmable functions using the Oview programmer STF HYKE – Rev00 Firmware: HK00 Run – 1... -
Page 2: Common Functions
COMMON FUNCTIONS Name This parameter enables the user to assign the automation with a name other than the original, to facilitate identification (e.g. “northern gate”). A name comprising maximum 24 characters, including spaces, is admitted. Series This parameter can be set with a value from 0 to 63; the factory setting is “0”. The series is a number that has to be assigned to each gearmotor, receiver or other device potentially connectable on a BusT4 network, to define its “classification area”, Subsequently, when using the automations in a complex system, all devices with the same assembly number can be controlled simultaneously. -
Page 3: Control Unit Functions
CONTROL UNIT FUNCTIONS Installation Bluebus search This function enables start-up of the procedure for learning the devices connected to the Bluebus input and the HALT input of the control unit of an automation. Important – To activate the device search, press “Run”. Position search This function enables an automatic search of positions: the control unit automatically measures the leaf opening angles and cal- culates the opening and deceleration positions. -
Page 4: Basic Parameters
Data deletion This function enables the user to delete the configuration of a control unit and the relative stored data, selecting items from a series. These items are: ❏ positions – enables deletion of all memorised positions; ❏ bluebus devices – enables deletion of the configuration of the Bluebus devices and the HALT input; ❏... - Page 5 mum speed) to 6 (maximum speed); the factory setting is 6. Parameter programming: select the required value by means of keys , then press “OK”. • opening deceleration speed This parameter enables programming of the motor speed during the deceleration phase of an Opening manoeuvre; it can be set with a value from 1 (minimum speed) to 8 (maximum speed);...
-
Page 6: Advanced Parameters
• closing time This parameter is expressed in seconds and can be set with a value from 0 to 10 seconds; the factory setting is 3 seconds. The function enables programming of the flashing time which indicates the imminent start of a Closing manoeuvre and is associated with the “preflash”... - Page 7 02. Then, again in “Advanced parameters”, select “command configuration” and select the command category corresponding top the command selected previously in step 01. Then select the required operating mode. There are three available inputs: • Input 1: This function enables the programming of Input 1, assigning a command as required, from those listed in Table 1. Input 1 is factory set with the “step-step”...
- Page 8 High priority step step Step step When this command is sent, the control unit program the required operating mode, se - activates the application to complete the next lecting in Table 1-A (command configu- manoeuvre following the previous one (or still in ra tion”...
- Page 9 Courtesy Light On/Off This command enables activation and deacti- vation of the courtesy light, programmable on Output 1, 2 and 3. CAUTION! - The courtesy light is switched off automatically if the relative time interval elapses, as programmed in the function “courtesy light time”...
- Page 10 COMMAND configuration This item covers the command categories associable with inputs 1 - 2 - 3 (refer to the section “input configuration – Table 1” to che ck the commands available). Each command category features various operating modes as described in a table (1-A, 1-B, etc.): Step step In this command category the user can select one of the operating modes specified in Table 1-A.
- Page 11 Open In this command category the user can select one of the operating modes specified in Table 1-C. TABLE 1-C: COMMAND CONFIGURATION OPERATING MODE DESCRIPTION Open - Stop - Open Operating mode set in factory (Input 2 - “open” com- mand).
- Page 12 Obstacle detection on opening In this command category the user can select one of the operating modes specified in Table 1-G. TABLE 1-G: COMMAND CONFIGURATION OPERATING MODE DESCRIPTION Halt When the control unit receives the command, it stops the Opening manoeuvre in progress. Halt and brief inversion When the control unit receives the command, it stops the Opening manoeuvre in progress immediately and activates the...
- Page 13 gate closed The programmed light indicates the operating status of the control unit. light on = application in maximum Closing position; light off = application in other positions Output active 24 Vdc / max 4 W maintenance indicator light The programmed light indicates the count of manoeuvres completed and therefore the need (or not) for system mainte- nance operations.
- Page 14 trolled with a single transmitter. WARNING – If this channel is not free on the control unit re - ceiver, as previously memorised with a command, the control unit activates exclusively the programmed output when the channel is activated with the transmitter, ignoring the com- mand to the motor.
- Page 15 light flashing during execution of entire manoeuvre = num- ber of manoeuvres between 80 and 100%; light always flashing = number of manoeuvres over 100%. Output active 24 Vdc / max 4 W flashing light This function enables the flashing light to indicate execution of a manoeuvre in progress with flashes at regular intervals (0.5 sec ON, 0.5 sec OFF).
- Page 16 with a single transmitter. WARNING – If this channel is not free on the control unit receiver, as previously memorised with a command, the control unit activates exclusively the pro- grammed output when the channel is activated with the trans- mitter, ignoring the command to the motor.
- Page 17 red traffic light This function indicates activity of the application during the phases of a Closing manoeuvre. slow flashing = execution of Closing manoeuvre; light permanently on = application in maximum Closing position; light off = application in other positions Output active 24 Vdc / max 4 W green traffic light This function indicates activity of the application during the...
- Page 18 Electric lock time This parameter is expressed in seconds and can be set with a value from 0 to 10 seconds; the factory setting is 2 seconds. This function enables programming of the electric lock activation time after the start of an opening manoeuvre (starting from the gate closed position).
- Page 19 POWER SUPPLY Indicates the type of electrical mains used by the automation: electric mains (120/230 Vac) or buffer battery (24 Vdc) MEMORY ERRORS Functions Indicates whether there is an error in the memorised data regarding the functions programmable with Oview. Bluebus Indicates whether there is an error in the memorised data regarding the configuration of the devices connected to the bluebus input.
- Page 20 Diagnostics of bluebus devices This function enables the display of the device type, operating status, and configuration of the devices connected to the Blue- bus output. These parameters are described in Table 7. TABLE 7: DIAGNOSTICS of bluebus devices PARAMETER DESCRIPTION Bluebus PHOTOCELLS:...
-
Page 21: Advanced Functions
This function enables the firmware of a control unit to be updated with another compatible version, without the obligation to change the board. To update, proceed as follows: 01. Download the firmware update file (the software update is available at the site internet www.nice-service.com) 02. In “Advanced Functions” select “Update firmware”;...
