Software Update Console

The table below defines what information is displayed with each column header.
Column header
Connectivity Status
Endpoint Status
System Name
Model
Software Version
GMT
Status
Software Update Tabs
Tabs have been added to the Software Update so that the administrator can easily access detailed information for a
system without having to click to the System Management Page.
General Tab
Contains pertinent information for software update, such as call status, software version and the system's local time.
Descriptors for these fields can be found here.
Status
Contains details explaining why the selected device is remaining in a pending state or why software update failed for
this device.
Status Details - Descriptor for current status.
Failure Reason - Describes why Soft Update failed.
Next Update Time - Details when this system will be updated.
The following only applies to a ViewStation or V-Series model:
Remove Address Book entries -Yes indicates that Address book entries will be removed after an update
Remove System files - Yes indicates the endpoint settings will be removed after an update
Passive FTP - Yes indicates the ReadiManager LX100 will perform Software Update in Passive FTP
mode vs. Active FTP.
Allow endpoint to be a DHCP server - Yes indicates that the endpoint will be a DHCP server.
Details
Records all steps during the Software Update process for the selected system. If Soft Update failed during the
process, then all steps until the point of failure will be logged here.
Polycom ReadiManager LX100 User Guide
Description
Green network icon - Indicates that Polycom ReadiManager LX100 can successfully
communicate with the system.
Green network icon with log - Polycom ReadiManager LX100 is logging system
information.
Red network icon- The server is unable to communicate with a system.
Yellow network icon - Indicates that Polycom ReadiManager LX100 is able to query
the system, but is unable to receive status updates.
Gray ball -The video endpoint is not in a call.
Green ball - A video endpoint is in a call.
Red Cross - A video endpoint user is requesting help.
System Identifier
Model of video endpoint
Software version currently loaded on endpoint
Offset from Greenwich mean time
Whether software updates are updating, pending, successful, failed
Chapter 4 Software Update 46
