Appendix
V-Series Admin Setup Menu
System Info :: Admin Setup :: Video Network ::
H.323 Settings
V-Series Field
Enable IP H.323
Display H.323 extension
Gatekeeper
V-Series Field
Use Gatekeeper
Gatekeeper IP address
Outbound Call Route
Use PathNavigator for
Multipoint Calls
Gateway
V-Series Field
Country Code
Area Code
Number
Gateway Number Type
Number of Digits in DID
Number of Digits in
extension
Polycom ReadiManager LX100 User Guide
IP Network
Type Meaning
Checkbox option Checked - Enables IP dialing.
Checkbox option Checked - Displays the IP dialing extension on the main call
screen.
Type Meaning
Pull down menu Indicates whether a gatekeeper will be used
User Defined Field IP address of Gatekeeper
Pull down menu Gateway—Select this option if your outbound call needs to be
handled by a Gateway.
ISDN—Select this option if the system is connected to an
ISDN line. ISDN is the default.
Checkbox Specifies whether multipoint calls use the system's internal
multipoint capability or the PathNavigator Conference on
Demand feature.
Type Meaning
User Defined Field Country code for the country in which the gateway is located.
User Defined Field Area code of the gateway.
User Defined Field Number of the gateway.
Pull down menu Specifies the gateway number type when dialing this endpoint.
User Defined Field Number of digits in the subscriber number, e.g., United States
is 7
User Defined Field Number of digits as determined by the dialing plan of the
organization to which the system belongs to.
