Appendix
System Information Window
Advanced Stats Tab
The Advance Network Statistics screen contains information about the status of a call. It describes how fast audio
and video is coming in and going out during a call. The statistics will continually refresh throughout the duration of the
video call. If the ViewStation is not in a call, the statistics will appear as dashes.
Polycom ReadiManager LX100 User Guide
Field Description
Tx
Audio rate Audio Rate transmitted
Video rate Transmitting video rate
Video Rate Used The actual amount of bandwidth being
used for video data
Video Frame Rate The current number of video frames per
second
Video FEC Errors The number of Forward Error Correction
(FEC) errors that have corrected in the
current call
LSD Protocol The current Low Speed Data (LSD)
channel protocol in use
LSD Rate The rate used for Low Speed Data (LSD)
channel communications
MLP Protocol The current MLP channel protocol in use
MLP Rate The rate used for MLP channel
communications
Remote System ID An identifier string sent by the remote
site (usually a manufacturer name)
Audio Packet loss The number of audio packets lost in
transmission
Audio Jitter The variance from average audio
transmission rate
Video packet loss The number of video packets lost in the
call
Video Jitter The variance from average video
transmission rate
ViewStation FX and EX
-
Rx
Receiving Audio rate
Receiving video rate
The actual amount of bandwidth being
used for video data
The current number of video frames per
second
The number of Forward Error Correction
(FEC) errors that have corrected in the
current call
The current Low Speed Data (LSD)
channel protocol in use
The rate used for Low Speed Data (LSD)
channel communications
The current MLP channel protocol in use
The rate used for MLP channel
communications
An identifier string sent by the remote
site (usually a manufacturer name)
The number of receiving audio packets
lost in the call
The variance from average audio
receiving rate
The number of video packets lost in
the call
The variance from average video
transmission rate
Appendix 99
