Appendix
ViewStation Admin Setup Menu
System Info :: Admin Setup ::
Cameras
ViewStation Field
Snapshot Camera
PIP
Far Control of Near Camera
Backlight Compensation
Camera Direction
Polycom ReadiManager LX100 User Guide
Video / Camera
Type Meaning
Radio Buttons Select the camera used for snapshots.
1
2. The ViewStation will use camera number 2 for
3. The ViewStation will use camera number 3 for
4. The ViewStation will use camera number 4 for
Radio Buttons Auto: The PiP window is displayed when a call is made and
when the remote control is not resting on a flat surface.
On: The PiP is displayed continuously.
Off: The PiP is not displayed.
Checkbox option Checked - The Far Control of Near Camera allows a user on the
far site to manipulate the camera by pressing the FAR button on
the remote control.
Checkbox option Checked - The camera automatically adjusts for low lighting.
Radio Buttons Normal - Normal camera direction is used when a speaker is
behind the ViewStation facing an audience. When the left button
is pressed, the camera will move right and when the right button
is pressed, the camera will move right.
Reversed - The reversed camera direction is used for
videoconferencing when the speaker is sitting at a conference
table.
The ViewStation will use camera number 1 for
snapshots.
snapshots.
snapshots.
snapshots.
Appendix 139
