Appendix
System Information Window
Advanced Stats Tab
This table displays the following Advanced Statistics information for the selected iPower.
Polycom ReadiManager LX100 User Guide
Field Description
Tx
Video Rate for people
Transmitting video rate
and content
Video Rate Used for The actual amount of bandwidth being
people and content used for video data
Video Frame Rate for The current number of video frames per
people and content second.
Video Packet Loss for (H.323 only) The number of video packets
people and content lost in the call.
Latency for people and (H.323 only) Average video packet round
content trip latency. This is a weighted average,
with most recent measurements having
highest weighting.
Audio rate The rate of audio packet transfer.
Audio Packet Loss (H.323 only) The number of audio
packets lost in the call
Audio Latency (H.323 only) Average audio packet round
trip latency. This is a weighted average,
with most recent measurements having
highest weighting.
Video FEC Errors The number of Forward Error Correction
(FEC) errors that have corrected in the
current call
LSD Protocol (H.320) The current Low Speed Data
(LSD) channel protocol in use
LSD Rate (H.320) The rate used for Low Speed
Data (LSD) channel communications
MLP Protocol (H.320) The current MLP channel
protocol in use
MLP Rate (H.320) The rate used for MLP channel
communications
iPower
-
Rx
Receiving video rate
The actual amount of bandwidth being
used for video data
The current number of video frames per
second.
(H.323 only) The number of video packets
lost in the call.
(H.323 only) Average video packet round
trip latency. This is a weighted average,
with most recent measurements having
highest weighting.
Receiving rate of audio packet transfer.
(H.323 only) The number of receiving
audio packets lost in the call.
(H.323 only) Average audio packet round
trip latency. This is a weighted average,
with most recent measurements having
highest weighting.
The number of Forward Error Correction
(FEC) errors that have corrected in the
current call
(H.320) The current Low Speed Data
(LSD) channel protocol in use
(H.320) The rate used for Low Speed
Data (LSD) channel communications
(H.320) The current MLP channel
protocol in use
(H.320) The rate used for MLP channel
communications
Appendix 116
