Polycom ReadiManagerLX100 Management Manual page 145

Appendix
ViewStation Admin Setup Menu
System Info :: Admin Setup ::
Phone/Audio
ViewStation Field
Mute Auto Answer Calls
Sound Effects Volume
VCR Audio Out Always On
Audio Quality
Acoustic Plus 716
Polycom ReadiManager LX100 User Guide
Phone/Audio
Type Meaning
Checkbox option Checked - The ViewStation will automatically place the
Microphone Pod in Mute when an incoming call is automatically
answered by the ViewStation.
Unchecked - The ViewStation will send audio to the far site
when a call is automatically answered.
User Defined Value Adjusts the volume of the sounds that the ViewStation makes
when you select an object on the screen with the remote control.
Checkbox option Checked - When a device (VCR, DVD or other) is connected to
the VCR IN port, the audio from that device is "Always On"
Un-checked - When the same device (VCR, DVD or other) is
connected to both the VCR IN and OUT ports of the ViewStation,
un-check this to prevent an audio feedback loop.
User Defined Value The Audio Quality Preference screen adjusts the line speed. At
above 168 kilobits per second, the system uses G.722 48Kb high-
fidelity audio. When placing a call at 168 Kilobits per second and
below, the system uses G.728 16Kb audio.
Checked - Enables endpoint to transmit audio at less than
half the rate of the previous standard. Hence, there is more
bandwidth left over for video.
Appendix 138
