Appendix
ViewStation Admin Setup Menu
System Info :: Admin Setup :: LAN / H.323 ::
QoS
ViewStation Field
Used Fixed Ports
TCP Ports
UDP Ports
Type of Service Field
Type of Service Value (IP
Precedence)
Type of Service Value
(DiffServ)
System is behind a NAT
Auto discover NAT address
Polycom ReadiManager LX100 User Guide
H.323
Type Meaning
Checkbox option Checked - Specifies the fixed ports assigned to ViewStation
when working with a firewall
User Defined Value TDP Ports open in firewall for IP communication
User Defined Value UDP Ports open in firewall for IP communication
Radio Buttons Specifies whether to use IP Prec or DiffServ parameters for the
Type of Service
User Defined Value Specifies the priority given IP packages sent to the ViewStation.
User Defined Value Specifies IP packet service requirements
User Defined Value Alerts ViewStation to use the IP address that appears in the
NAT outside (WAN) address field as its external IP address.
When using a Virtual Private Network (VPN) for network
connection, make sure that System is behind a NAT is NOT
selected.
Checkbox option Checked - Option for the ViewStation to discover its NAT
outside (WAN) address automatically
Appendix 132
