Appendix
Communication Service Ports used for Polycom Management Software Applications
Communication across the network for Polycom products requires the usage of certain Internet service ports.
Polycom ReadiManager LX100 communicates with the web client, video devices and other services. In the tables
below, "Direction" indicates how a particular communication is initiated; for example, "Web browser ReadiManager
LX100" means the web browser opens a connection with ReadiManager LX100 which is then used to interchange
information.
The Web Client
The web client is a web browser running on a PC station that is used to access ReadiManager LX100, Path Navigator,
or video devices. The table below shows the protocol and port used. The ports listed must be open for two-way
communication.
Direction
Web browser
ReadiManager LX100
Web browser
except for ViaVideo
Web browser
Web browser
Devices web server
Web browser
PathNavigator
Polycom ReadiManager LX100 and video devices communications
Different features offered in ReadiManager LX100 use different ports when communicating with video devices.
The port most often used is port 80. However, other protocols such as FTP and Telnet require the usage of ports
other than 80.
Polycom ReadiManager LX100 User Guide
Protocol
HTTP: TCP
video devices HTTP: TCP
ViaVideo HTTP: TCP
Other HTTP: TCP
HTTP: TCP
Ports Purpose
80 Web client communicating with
ReadiManager LX100
80 Web client communicating with video
devices user interface
3603 Web client communicating with
ViaVideo web interface
Arbitrary port Web client communicating with Other
(assigned by admin Devices web interface
when adding
this device to
ReadiManager LX100)
80 Web client communicating with
PathNavigator
Appendix 179
