Global Directory Console - Polycom ReadiManagerLX100 Management Manual

Global Directory Console

Address Book Pull Down Menu
The Address Book Menu lists the Address Books created in Polycom ReadiManager LX100 or imported address
books from other servers. The default address book is titled "MAIN" unless an administrator has modified its name.
Other address books can be viewed by using the pull down menu.
Address window
The Address window lists the addresses for the selected address book. These entries include static, dynamic and
replicated entries. Static entries are addresses that have been manually added to the database. Dynamic entries are
endpoint entries that auto-register with Polycom ReadiManager LX100. Replicated entries are addresses that were
replicated from another Polycom ReadiManager LX100 or Global Management System server through ILS or LDAP
replication.
• The red booklet is an entry that has been dynamically added to the system.
• Devices with a white booklet are entries that have been added to the system manually.
• A blue booklet indicates that these entries are replicated entries from another Directory servers.
All of the information that is pertinent for calling by video is listed on this screen. The name and more importantly, the
IP address or ISDN number is also listed. The right hand side of this window contains the utility buttons for address
book modification and management, importing and exporting the Global Directory and for server configurations.
Polycom ReadiManager LX100 User Guide
Figure 3.1 Global Directory
Alphabetical list of System Type
systems ViewStation or
ViaVideo
System's IP Pull down menu
address and ISDN for Address Books
number
Chapter 3
Modify static
and dynamic
addresses
Create, edit
address books
Import
and export
addresses
Set LDAP and
ILS support
Global Directory 22
