Appendix
System Information Window
Network Stats Tab
This window is only active during a call. The Network Statistics screen describes the video and audio protocols used
and the rates at which a call travels over the network and to the party you are calling. If the ViewStation is not in a
call, the statistics will appear as dashes.
Polycom ReadiManager LX100 User Guide
Field Description
B1
Tx Clock Rate Transmission rate
Rx Clock Rate Receiving clock rate
Errors The number of CRC errors that have
occurred during the current call
Sync The number of synchronization errors
that have occurred during the current call
Video Protocol The current video protocol in use (H.261,
H.263, etc.)
Video format The format of the video data (QCIF, FCIF,
etc.)
Audio Protocol The current audio protocol in use (G.711,
G.722, G.728, etc.)
Comm Protocol The communications protocol in use
(H.221, H.223, etc.)
ViewStation
-
B2
Transmission rate
Receiving clock rate
The number of CRC errors that have
occurred during the current call
The number of synchronization errors
that have occurred during the current call
The current video protocol in use (H.261,
H.263, etc.)
The format of the video data (QCIF, FCIF,
etc.)
The current audio protocol in use (G.711,
G.722, G.728, etc.)
The communications protocol in use
(H.221, H.223, etc.)
Appendix 97
