5.1.3 Functional Specifications

A port configured as a virtual Phantom master device on the MVI56-PNPM
module will actively issue Phantom commands to other nodes on the Phantom
network. One hundred commands are supported on each port. Additionally, the
master ports have an optimized polling characteristic that will poll slaves with
communication problems less frequently. The ControlLogix processor can be
programmed to control the activity on the port by actively selecting commands
from the command list to execute or issuing commands directly from the ladder
logic. The ControlLogix processor also has the ability to control the scanning of
slaves on the port.

5.1.4 Hardware Specifications

Specification
Backplane Current Load
Operating Temperature
Storage Temperature
Shock
Relative Humidity
LED Indicators
Debug/Configuration port (CFG)
CFG Port (CFG)
Application ports (PRT1 & PRT2)
Full hardware handshaking control, providing radio, modem and multi-drop support
Software configurable
communication parameters
App Ports (P1,P2) (Serial modules)
Shipped with Unit
Page 50 of 91
Description
800 mA @ 5 V DC; 3mA @ 24V DC
0 to 60°C (32 to 140°F)
-40 to 85°C (-40 to 185°F)
30g Operational
50g non-operational
Vibration: 5 g from 10 to 150 Hz
5% to 95% (non-condensing)
Module Status
Backplane Transfer Status
Application Status
Serial Activity
RJ45 (DB-9M with supplied cable)
RS-232 only
Baud rate: 110 to 115,200 baud, depending on protocol
RS-232 and 422
Parity: none, odd or even
Data bits: 5, 6, 7, or 8
Stop bits: 1 or 2
RTS on/off delay: 0 to 65535 milliseconds
RJ45 (DB-9M with supplied cable)
RS-232 handshaking configurable
500V Optical isolation from backplane
RJ45 to DB-9M cables for each port
6-foot RS-232 configuration cable
Reference
