MVI56-CAS ♦ ControlLogix Platform
Teledyne CA Slave Module

5.1.3 Hardware Specifications

Specification
Backplane Current Load
Operating Temperature
Storage Temperature
Shock
Relative Humidity
LED Indicators
Debug/Configuration port (CFG)
CFG Port (CFG)
Application ports (PRT1 & PRT2)
Full hardware handshaking control, providing radio, modem and multi-drop support
Software configurable
communication parameters
App Ports (P1,P2) (Serial modules)
Shipped with Unit

5.1.4 Functional Specifications

Function codes
o 1: Read output data
o 2: Read analog data
o 3: Read meter data
o 10: Read frozen analog values
o 11: Read frozen meter data
o 16: Read all data
o 20: Read tank data from RTU
o 30: Control momentary select
o 31: Control momentary operate
o 32: Control continuous select
o 33: Control continuous operate
Page 48 of 86
Description
800 mA @ 5 V DC; 3mA @ 24V DC
0 to 60°C (32 to 140°F)
-40 to 85°C (-40 to 185°F)
30g Operational
50g non-operational
Vibration: 5 g from 10 to 150 Hz
5% to 95% (non-condensing)
Module Status
Backplane Transfer Status
Application Status
Serial Activity
RJ45 (DB-9M with supplied cable)
RS-232 only
Baud rate: 110 to 115,200 baud, depending on protocol
RS-232 and 422
Parity: none, odd or even
Data bits: 5, 6, 7, or 8
Stop bits: 1 or 2
RTS on/off delay: 0 to 65535 milliseconds
RJ45 (DB-9M with supplied cable)
RS-232 handshaking configurable
500V Optical isolation from backplane
RJ45 to DB-9M cables for each port
6-foot RS-232 configuration cable
Reference
