Start Here - ProSoft Technology MVI69-GSC CompactLogix User Manual

MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module
1

Start Here

In This Chapter

System Requirements ............................................................................. 8

Package Contents ................................................................................... 9

Installing ProSoft Configuration Builder Software .................................. 10

Setting Jumpers ..................................................................................... 10

Install the Module in the Rack ................................................................ 11
To get the most benefit from this User Manual, you should have the following skills:

Rockwell Automation
logic, and transfer the ladder logic to the processor

Microsoft Windows: install and launch programs, execute menu commands,
navigate dialog boxes, and enter data

Hardware installation and wiring: install the module, and safely connect and
CompactLogix or MicroLogix devices to a power source and to the MVI69-GSC
module's application port(s)
